Philips 65BDL3050Q - External Equipment Connectivity; DisplayPort, Audio, and Daisy-chaining

65BDL3050Q
11
3.2.3. Using DisplayPort input
PC
DisplayPort Out
[DisplayPort IN]
HDMI 1 IN HDMI 2 IN
DP IN
RS232
OUT
3.3. Connecting Audio Equipment
3.3.1. Connecting an external audio device
Stereo Amplifier
[AUDIO OUT] Audio In
AUDIO OUT
3.4. Connecting Multiple Displays in a Daisy-chain Configuration
You can interconnect multiple displays to create a daisy-chain conguration for applications such as a menu board.
3.4.1. Display control connection
Connect the [RS232 OUT] connector of DISPLAY 1 to the [RS232 IN] connector of DISPLAY 2.
DISPLAY 1
PC
DISPLAY 2
[RS-232C IN]
[RS-232C]
[RS-232C OUT] [RS-232C IN]
