9-1 9-1
PCS 107 215
ELECTRICAL PARTSLIST - COMBI BOARD
- CAPACITIORS - - CAPACITIORS -
2101 4822 122 33195 100pF 10% 50V 2628 4822 126 13507 91pF 5% 50V
2102 4822 122 33848 47pF 5%SL 50V 2629 4822 124 40248 10µF 20% 63V
2103 4822 124 40248 10µF 20% 63V 2630 4822 124 40248 10µF 20% 63V
2104 4822 124 40248 10µF 20% 63V 2631 4822 121 43856 4.7nF 5% 250V
2105 4822 122 33191 22pF 5% 50V 2632 4822 121 43856 4.7nF 5% 250V
2106 4822 125 50681 Var Cpacitior 2633 4822 122 10466 220pF 10% 50V
2108 4822 122 10465 4,7pF 10% 50V 2634 4822 122 10466 220pF 10% 50V
2109 4822 122 32147 22pF 2% N470 100V 2635 4822 124 40433 47µF 20% 25V
2110 4822 126 12229 8,2pF N750 50V 2636 4822 124 40433 47µF 20% 25V
2112 4822 124 40433 47µF 20% 25V 2637 4822 121 42469 5,6nF 5% 250V
2113 4822 124 40746 0,22µF 20% 63V 2638 4822 121 42469 5,6nF 5% 250V
2114 4822 126 12787 330pF 10% Y5V 50V 2639 4822 122 33197 1nF 10% 50V
2115 4822 124 40769 4,7µF 20% 100V 2640 4822 122 33197 1nF 10% 50V
2116 4822 121 41856 22nF 5% 250V 2641 4822 126 11585 22nF +80-20% Y5V 25V
2117 4822 124 21913 1µF 20% 63V 2642 4822 126 11585 22nF +80-20% Y5V 25V
2118 4822 124 21913 1µF 20% 63V 2650 4822 124 41584 100µF 20% 10V
2119 4822 121 41856 22nF 5% 250V 2651 4822 124 81151 22µF 50V
2120 4822 124 21913 1µF 20% 63V 2652 4822 121 10685 1,8nF 10% 50V
2121 4822 124 41407 0,47µF 20% 63V 2653 4822 124 40433 47µF 20% 25V
2122 4822 124 41407 0,47µF 20% 63V 2654 4822 121 51387 10nF 20% 16V
2125 2020 561 90063 2,2pF 10% 50V 2655 4822 121 51387 10nF 20% 16V
2248 5322 121 42386 100nF 5% 63V 2657 4822 122 33197 1nF 10% 50V
2249 5322 121 42386 100nF 5% 63V 2658 4822 122 33197 1nF 10% 50V
2250 5322 121 42386 100nF 5% 63V 2800 4822 124 21913 1µF 20% 63V
2251 5322 121 42386 100nF 5% 63V 2801 4822 124 21913 1µF 20% 63V
2252 2020 561 90365 100nF +80/-20% 50V 2802 4822 121 51387 10nF 20% 16V
2253 2020 561 90365 100nF +80/-20% 50V 2803 4822 124 40433 47µF 20% 25V (For Z1050)
2274 4822 124 40769 4,7µF 20% 100V 2803 4822 124 41584 100µF 20% 10V (For AZ1055)
2301 4822 121 51387 10nF 20% 16V 2804 4822 126 12878 1,5nF 10% 16V
2302 4822 121 51387 10nF 20% 16V 2805 4822 121 42408 220nF 5% 63V
2303 4822 124 40746 0,22µF 20% 63V 2806 4822 126 14316 680pF 10% 50V Y5P
2304 4822 124 40746 0,22µF 20% 63V 2807 4822 122 33191 22pF 5% 50V
2305 4822 124 41407 0,47µF 20% 63V 2808 4822 124 40433 47µF 20% 25V
2306 4822 124 41407 0,47µF 20% 63V 2809 4822 122 10459 560pF 10% 50V
2307 4822 124 40433 47µF 20% 25V 2810 4822 122 10459 560pF 10% 50V
2308 4822 124 40769 4,7µF 20% 100V 2811 4822 126 12702 270pF 10% Y5P 50V
2309 4822 126 14316 680pF 10% 50V Y5P 2812 4822 126 12702 270pF 10% Y5P 50V
2310 4822 126 14316 680pF 10% 50V Y5P 2813 4822 126 12339 2,2nF 10% Y5R
2311 4822 124 40433 47µF 20% 25V 2814 4822 126 13677 39pF 5% 50V
2312 4822 124 40433 47µF 20% 25V 2815 4822 121 51387 10nF 20% 16V
2313 4822 124 41407 0,47µF 20% 63V 2816 4822 124 41407 0,47µF 20% 63V
2314 4822 124 41407 0,47µF 20% 63V 2817 4822 122 10577 3,3nF 10% 16V
2315 4822 123 14025 2200µF 20% 16V 2818 4822 124 21913 1µF 20% 63V
2317 4822 124 40207 100µF 20% 25V 2819 5322 121 42386 100nF 5% 63V
2319 4822 124 80195 470µF 20% 10V 2821 4822 124 40248 10µF 20% 63V
2320 4822 124 80195 470µF 20% 10V 2822 4822 126 11585 22nF +80-20% Y5V 25V
2321 2020 561 90365 100nF +80/-20% 50V 2823 4822 124 40769 4,7µF 20% 100V
2625 4822 122 33197 1nF 10% 50V 2824 4822 124 41407 0,47µF 20% 63V
2626 4822 122 33197 1nF 10% 50V 2825 4822 122 10462 15pF 5% NP0
2627 4822 126 13507 91pF 5% 50V 2826 4822 121 51252 470nF 5% 63V
ELECTRICAL PARTSLIST - COMBI BOARD
- CAPACITIORS - - RESISTORS -
2827 4822 124 40433 47µF 20% 25V 3101 4822 100 20167 VR 50K 30% 0,1W
2828 4822 124 40248 10µF 20% 63V 3102 4822 116 52297 68K 5% 0,5W
2829 5322 121 42489 33nF 5% 250V 3104 4822 116 52256 2K2 5% 0,5W
2830 4822 122 10319 82pF 5% 50V 3106 4822 116 52231 820R 5% 0,5W
2831 4822 121 41856 22nF 5% 250V 3107 4822 116 52191 33R 5% 0,5W
2832 4822 124 22652 2,2µF 20% 50V 3113 4822 116 52234 100K 5% 0,5W
2833 4822 124 40433 47µF 20% 25V 3114 4822 116 52234 100K 5% 0,5W
2834 2020 561 90365 100nF +80/-20% 50V 3207 4822 116 52191 33R 5% 0,5W
2835 4822 122 33195 100pF 10% 50V 3208 4822 116 52191 33R 5% 0,5W
2836 4822 124 40433 47µF 20% 25V 3209 4822 116 52234 100K 5% 0,5W
2838 4822 122 33197 1nF 10% 50V 3300 4822 101 11826 VR 50K 20% 0.025W
2839 4822 122 33191 22pF 5% 50V 3301 4822 116 52256 2K2 5% 0,5W
2841 4822 126 13677 39pF 5% 50V 3302 4822 116 52256 2K2 5% 0,5W
2842 4822 124 40433 47µF 20% 25V 3303 4822 116 52243 1K5 5% 0,5W
2843 4822 126 13098 5,6nF 20% 16V 3304 4822 116 52243 1K5 5% 0,5W
2844 4822 122 33195 100pF 10% 50V 3305 4822 116 83883 470R 5% 0,5W
2846 4822 122 33197 1nF 10% 50V 3306 4822 116 83883 470R 5% 0,5W
2848 4822 122 33197 1nF 10% 50V 3307 4822 116 52219 330R 5% 0,5W
2849 4822 122 33195 100pF 10% 50V 3308 4822 116 52219 330R 5% 0,5W
2850 4822 124 40248 10µF 20% 63V 3309 4822 116 52238 12K 5% 0,5W
2851 4822 126 13312 6.8nF 20% Y5R 16V 3310 4822 050 11002 1K 1% 0,4W
2852 4822 126 13312 6.8NF 20% Y5R 16V 3311 4822 050 11002 1K 1% 0,4W
2854 4822 122 33195 100pF 10% 50V 3313 4822 116 52206 120R 5% 0,5W
2855 4822 122 33195 100pF 10% 50V 3314 4822 116 52206 120R 5% 0,5W
2856 4822 122 33195 100pF 10% 50V 3315 4822 050 21003 10K 1% 0,6W
2857 4822 122 33195 100pF 10% 50V 3316 4822 050 21003 10K 1% 0,6W
2858 4822 122 33195 100pF 10% 50V 3551 4822 116 52256 2K2 5% 0,5W
2859 4822 121 51387 10nF 20% 16V 3552 4822 116 52256 2K2 5% 0,5W
2860 4822 124 40433 47µF 20% 25V 3553 4822 116 83961 6K8 5%
2871 4822 126 11714 4,7nF 20% 3554 4822 116 83961 6K8 5%
2873 2020 561 90365 100nF +80/-20% 50V 3625 4822 116 83883 470R 5% 0,5W
2874 2020 561 90365 100nF +80/-20% 50V 3626 4822 116 83883 470R 5% 0,5W
2876 2020 561 90365 100nF +80/-20% 50V 3627 4822 116 52264 27K 5% 0,5W
2880 4822 122 33197 1nF 10% 50V 3628 4822 116 52264 27K 5% 0,5W
2881 4822 124 11912 220µF 20% 6,3V 3629 4822 116 83883 470R 5% 0,5W
2890 2020 561 90365 100nF +80/-20% 50V 3630 4822 116 83883 470R 5% 0,5W
2891 4822 121 51387 10nF 20% 16V 3631 4822 116 52219 330R 5% 0,5W
2892 4822 124 40433 47µF 20% 25V 3632 4822 116 52219 330R 5% 0,5W
2893 4822 124 40433 47µF 20% 25V 3633 4822 116 52272 330K 5% 0,5W
2895 4822 124 22652 2,2µF 20% 50V 3634 4822 116 52272 330K 5% 0,5W
2896 4822 124 22652 2,2µF 20% 50V 3635 4822 116 83961 6K8 5%
2900 4822 122 10466 220pF 10% 50V 3636 4822 116 83961 6K8 5%
2901 4822 122 10466 220pF 10% 50V 3637 4822 116 52264 27K 5% 0,5W
2902 4822 122 10466 220pF 10% 50V 3638 4822 116 52264 27K 5% 0,5W
2903 4822 122 10466 220pF 10% 50V 3639 4822 050 21003 10K 1% 0,6W
2904 2020 561 90365 100nF +80/-20% 50V 3640 4822 050 21003 10K 1% 0,6W
2905 2020 561 90365 100nF +80/-20% 50V 3641 4822 116 52228 680R 5% 0,5W
2906 4822 122 10466 220pF 10% 50V 3642 4822 116 52228 680R 5% 0,5W
2907 4822 122 10466 220pF 10% 50V 3643 4822 116 52175 100R 5% 0,5W
3644 4822 116 52175 100R 5% 0,5W
