Philips AZ1050 - Electrical Partslist - Front Board

PCS 107 218
9-4
ELECTRICAL PARTSLIST - FRONT BOARD
- CAPACITIORS -
2901 4822 122 33519 470pF 10% 50V
2902 4822 122 33519 470pF 10% 50V
2903 4822 124 23432 100µF 20% 10V
2904 4822 122 33519 470pF 10% 50V
2905 4822 122 33519 470pF 10% 50V
- RESISTORS -
3872 4822 116 83882 39K 5% 0,5W
3873 4822 116 52257 22K 5% 0,5W
3875 4822 116 52256 2K2 5% 0,5W
3876 4822 116 52283 4K7 5% 0,5W
3901 4822 116 52257 22K 5% 0,5W
3902 4822 116 52234 100K 5% 0,5W
3903 4822 116 52234 100K 5% 0,5W
3904 4822 116 52175 100R 5% 0,5W
3905 4822 050 21003 10K 1% 0,6W
3906 4822 050 21003 10K 1% 0,6W
- MISCELLANEOUS -
1800 4822 276 13114 Push Switch
1801 4822 276 13114 Push Switch
1802 4822 276 13114 Push Switch
1803 4822 276 13114 Push Switch
1804 4822 276 13114 Push Switch
1820 9322 146 49682 LCD Display
7901 5322 209 11147 IC HEF4093BT
7900 9322 155 82667 IR Receiver TSOP2236 (For AZ1055)
Note:Only these parts metioned in the list are
normal service parts.
