Philips AZ1050 - Page 27

9-3
PCS 107 217
ELECTRICAL PARTSLIST - COMBI BOARD
- RESISTORS - -DIODES -
3903 4822 050 12203 22K 1% 0,4W 6850 4822 130 31881 Diode BZX79-B3V0
3904 4822 050 11503 15K 1% 0,4W 6851 5322 130 34834 Diode BZX79-C3V6
3905 4822 050 16802 6K8 1% 0,4W
3906 4822 050 11503 15K 1% 0,4W -IC & TRANSISTORS -
3907 4822 050 11503
15K 1% 0,4W (For AZ1050)
7101 4822 209 32746 IC TEA5711T/N2
3907 4822 050 21003
10K 1% 0,6W (For AZ1055) 7102 4822 130 44503 Trans BC547C
3908 4822 050 11503
15K 1% 0,4W (For AZ1050) 7300 4822 209 31544 IC TA8227P
3908 4822 050 21003
10K 1% 0,6W (For AZ1055) 7301 4822 130 40959 Trans BC547B
3909 4822 050 11503 15K 1% 0,4W 7601 4822 130 44503 Trans BC547C
3910 4822 050 11503 15K 1% 0,4W
7625 9322 140 00668 IC AN7323S (For AZ1050)
3912 4822 050 12203 22K 1% 0,4W 7625 4822 209 32918 IC AN7318S (For AZ1055)
3913 4822 050 11503 15K 1% 0,4W 7626 4822 130 40959 Trans BC547B
3914 4822 050 11503 15K 1% 0,4W 7800 4822 209 15932 IC TMP47C422F (For AZ1050)
3915 4822 050 12203 22K 1% 0,4W 7800 4822 209 17363 IC TMP47C422F (For AZ1055)
3916 4822 050 11503 15K 1% 0,4W
7801 4822 209 16076 IC M65824FP/ES5.0
3917 4822 050 11503 15K 1% 0,4W 7803 4822 209 90496 IC M62475FP
9860 4822 051 20008 Jumper 7805 4822 209 32636 IC LA6531 (For AZ1050)
9861 4822 051 20008 Jumper 7805 4822 209 32852 IC TDA7073A/N2 (For AZ1055)
9862 4822 051 20008 Jumper 7806 4822 209 32636 IC LA6531 (For AZ1050)
-COILS & FILTERS - 7806 4822 209 32852 IC TDA7073A/N2 (For AZ1055)
7850 9322 003 63676 Trans TBC327-40
5101 4822 157 70513 Coil FM 7851 4822 130 44568 Trans BC557B
5102 2422 535 94985 Coil 64µH 5% 7852 9322 003 63676 Trans TBC327-40
5104 4822 157 11843 Coil MD7B-01F 7853 4822 130 44503 Trans BC547C
5105 4822 157 71145 Coil 270µH
5106 4822 157 70499 Coil IFT AM 7854 4822 130 42231 Trans BC557C
7855 4822 130 44503 Trans BC547C
5107 4822 242 81154 Filter KMFC5058-Z
5108 4822 156 11146 Coil IFT AM -MISCELLANEOUS -
5201 4822 157 70826 Coil 2,4µH
5625 4822 157 10371 Coil Var 100kHz 1002 4822 240 10248 Loudspeaker 4 Ohm 6 W
5801 4822 157 70826 Coil 2,4µH 1003 4822 240 10248 Loudspeaker 4 Ohm 6 W
1006 4822 265 20318 Mains Socket
5803 4822 242 73557 Filter CST8,46MTW-TF01 1007 4822 277 21794 Volt Selector (For -/01/11)
1102 2422 549 44211 Ferrite Bar 5x13x55
-DIODES -
1250 4822 277 11739 Slide Switch
6101 4822 130 30621 Diode 1N4148 1302 2422 026 05076 Headphone Socket
6102 4822 130 30621 Diode 1N4148 1350 4822 276 12648 Push Switch
6250 4822 130 31878 Diode 1N4003G 1626 4822 277 11504 Push Switch
6251 4822 130 31878 Diode 1N4003G 1807 4822 276 13963 CD Door Switch
6252 4822 130 31878 Diode 1N4003G
5001 3140 118 32680 Transformer (For -/00/14)
6253 4822 130 31878 Diode 1N4003G 5001 4822 146 10875 Transformer (For -/01/11)
6256 4822 130 30621 Diode 1N4148 5001 3140 118 32690 Transformer (For -/10)
6300 4822 130 30621 Diode 1N4148 5001 3140 118 32700 Transformer (For -/17)
6625 4822 130 34167 Diode BZX79-B6V2 8003 4822 320 12637 Flexible Foil 15P
6800 4822 130 31881 Diode BZX79-B3V0
6801 4822 130 31881 Diode BZX79-B3V0
6802 4822 130 30621 Diode 1N4148
6803 4822 130 30621 Diode 1N4148
6804 4822 130 30621 Diode 1N4148
Note:Only these parts metioned in the list are
6805 3198 010 53980 Diode BZX79-B3V9 normal service parts.
