13-1 13-1
PCS 107 291
ELECTRICAL PARTSLIST - FRONT BOARD
- FILTER & INDUCTORS -
L201 9965 000 08562 INDUCTOR 2.2µH
L202 9965 000 08562 INDUCTOR 2.2µH
L203 9965 000 08558 INDUCTOR 100µH
X201 4822 242 73769 FILTER CST4,19MGW
- DIODES -
D201 9965 000 08563 ZENER DIODE 3.9V 1/2W
D202 5322 130 31504 DIODE BZX79-B3V3
D203 5322 130 34337 DIODE BAV99
LD201 4822 130 82978 LED LTL-16KPE-P
LD616 9965 000 08564 LED GREEN
LD617 9965 000 08564 LED GREEN
LD618 9965 000 08564 LED GREEN
LD619 9965 000 08564 LED GREEN
- IC & TRANSISTORS -
IC201 9965 000 08557 IC TMP86CH29F
IC202 9965 000 04931 IC M24C01-WMN6
Q201 4822 130 60511 TRANS BC847B
Q202 4822 130 60511 TRANS BC847B
Q203 4822 130 60511 TRANS BC847B
Q204 4822 130 60511 TRANS BC847B
Q205 4822 130 60511 TRANS BC847B
Q206 4822 130 60511 TRANS BC847B
- MISCELLANEOUS -
SW201 4822 276 13443 PUSH SWITCH
SW202 4822 276 13443 PUSH SWITCH
SW203 4822 276 13443 PUSH SWITCH
SW204 4822 276 13443 PUSH SWITCH
SW205 4822 276 13443 PUSH SWITCH
SW206 4822 276 13443 PUSH SWITCH
SW207 4822 276 13443 PUSH SWITCH
SW208 4822 276 13443 PUSH SWITCH
SW209 4822 276 13443 PUSH SWITCH
9965 000 08568
Note: Only these parts mentioned in the list are
normal service parts.
ELECTRICAL PARTSLIST - FEATURE BOARD
- RESISTOR - - IC & TRANSISTORS -
VR601 9965 000 08543 VARIABLE RESISTOR Q625 4822 130 60511 TRANS BC847B
Q626 4822 130 60511 TRANS BC847B
- INDUCTORS - Q627 4822 130 60511 TRANS BC847B
Q628 4822 130 60511 TRANS BC847B
L601 9965 000 08548 FIXED INDUCTOR 0.47µH Q629 4822 130 60373 TRANS BC856B
L602 9965 000 08548 FIXED INDUCTOR 0.47µH
Q630 9965 000 08547 TRANS KSC 2331-Y
- DIODES - Q631 5322 130 44647 TRANS BC368
Q632 5322 130 44647 TRANS BC368
D601 4822 130 83757 DIODE BAS216
D602 4822 130 83757 DIODE BAS216 - MISCELLANEOUS -
D603 4822 130 83757 DIODE BAS216
D604 4822 130 83757 DIODE BAS216 SW601 4822 277 11864 SLIDE SWITCH
D605 4822 130 83757 DIODE BAS216 SW602 4822 273 10366 ROTARY SWITCH
D606 4822 130 83757 DIODE BAS216 SW611 9965 000 08542 TACT SWITCH
D608 4822 130 30621 DIODE 1N4148 SW612 9965 000 08542 TACT SWITCH
D609 4822 130 30621 DIODE 1N4148 SW613 9965 000 08542 TACT SWITCH
D610 4822 130 30621 DIODE 1N4148
D611 4822 130 30621 DIODE 1N4148 Note: Only these parts mentioned in the list are
normal service parts.
D612 4822 130 30621 DIODE 1N4148
D613 4822 130 30621 DIODE 1N4148
LED601 9965 000 08556 LED 3G4SC-8 GREEN
LED602 9965 000 08556 LED 3G4SC-8 GREEN
LED603 9965 000 08556 LED 3G4SC-8 GREEN
LED604 9965 000 08549 LED 304HD-7 ORANGE
LED605 9965 000 08549 LED 304HD-7 ORANGE
- IC & TRANSISTORS -
IC601 4822 209 10264 IC HEF4069UBP
IC602 5322 209 83125 IC LM324D
IC603 4822 209 60177 IC LM339D
Q601 4822 130 60511 TRANS BC847B
Q602 4822 130 60511 TRANS BC847B
Q603 4822 130 60511 TRANS BC847B
Q604 9965 000 04928 TRANS ON4986
Q605 9965 000 04928 TRANS ON4986
Q606 9965 000 04928 TRANS ON4986
Q607 9965 000 04928 TRANS ON4986
Q608 4822 130 60511 TRANS BC847B
Q609 4822 130 60511 TRANS BC847B
Q610 4822 130 60511 TRANS BC847B
Q611 4822 130 60511 TRANS BC847B
Q612 4822 130 60511 TRANS BC847B
Q613 4822 130 60511 TRANS BC847B
Q614 4822 130 60511 TRANS BC847B
Q615 4822 130 60511 TRANS BC847B
Q618 4822 130 60511 TRANS BC847B
Q619 4822 130 60511 TRANS BC847B
Q620 4822 130 60511 TRANS BC847B
Q621 4822 130 60511 TRANS BC847B
Q622 4822 130 60511 TRANS BC847B
Q623 4822 130 60511 TRANS BC847B
Q624 4822 130 60511 TRANS BC847B
ELECTRICAL PARTSLIST - AF & POWER BOARD
- COILS -
5300 9965 000 08569 RF COIL 0.36µH
5301 9965 000 08569 RF COIL 0.36µH
5302 9965 000 08569 RF COIL 0.36µH
5303 9965 000 08569 RF COIL 0.36µH
- DIODES -
6300 4822 130 82079 DIODE D3SBA20
6312 4822 130 30621 DIODE 1N4148
6313 5322 130 31504 DIODE BZX79-B3V3
6314 9965 000 08563 ZENER DIODE 3.9V 1/2W
6315 4822 130 34174 DIODE BZX79-B4V7
6316 5322 130 34331 DIODE BAV70
6317 4822 130 83757 DIODE BAS216
6318 4822 130 83757 DIODE BAS216
6319 4822 130 83757 DIODE BAS216
- IC & TRANSISTORS -
7300 4822 130 41246 TRANS BC327-25
7301 4822 130 41246 TRANS BC327-25
7302 4822 130 41246 TRANS BC327-25
7303 4822 130 60373 TRANS BC856B
7304 4822 130 60511 TRANS BC847B
7305 9322 133 18682 IC AN7125P
7306 4822 130 40981 TRANS BC337-25
7307 4822 130 40981 TRANS BC337-25
7308 4822 130 41246 TRANS BC327-25
7309 4822 130 41246 TRANS BC327-25
7310 4822 130 60373 TRANS BC856B
7311 4822 130 60373 TRANS BC856B
7312 4822 130 41246 TRANS BC327-25
7313 4822 130 60373 TRANS BC856B
7314 4822 130 60511 TRANS BC847B
7315 4822 130 60511 TRANS BC847B
7316 4822 130 41246 TRANS BC327-25
7317 4822 130 41246 TRANS BC327-25
7318 4822 130 40981 TRANS BC337-25
- MISCELLANEOUS -
1310 4822 071 52502 FUSE 2.5A
1301 4822 071 53152 FUSE 3.15A
Note:Only these parts mentioned in the list are
normal service parts.
ELECTRICAL PARTSLIST - MISC
- MISCELLANEOUS -
1306 2422 026 05076 HEADPHONE JACK
REV201 9965 000 04961 RECEIVER (FOR AZ2035)
9965 000 08570 FFC CABLE 4P 170mm
9965 000 08571 FFC CABLE 5P 210mm
9965 000 08572 FFC CABLE 6P 220mm
9965 000 08573 FFC CABLE 6P 230mm
9965 000 08574 FFC CABLE 6P 320mm
9965 000 08575 FFC CABLE 12P 120mm
9965 000 08576 FFC CABLE 13P 100mm
9965 000 08583 FFC CABLE 17P 100MM
9965 000 08577 AC SOCKET (NOT FOR -/17)
9965 000 08584 AC SOCKET (FOR -/17)
9965 000 08578 TRANSF 230V (FOR -/00/05/10)
3140 118 32640 TRANSF 120/230V (FOR -/11/16)
9965 000 08585 TRANSF 120V (FOR -/17)
4822 277 21794 VOLT SELECTOR (FOR -/11/16)
9965 000 08579 SPEAKER 1.5" 6 OHM 8W
9965 000 08580 SPEAKER 4" 8 OHM 12W
Note: Only these parts mentioned in the list are
normal service parts.
