13-2 13-2
PCS 107 292
ELECTRICAL PARTSLIST - TUNER BOARD ECO6
- CAPACTORS - - CAPACTORS -
2101 4822 126 13692 47pF 1% NP0 63V 2188 4822 122 33177 10nF 20% X7R 50V
2103 5322 122 31647 1nF 10% X7R 63V 2189 4822 126 14076 220nF 80/20% 25V
2104 5322 122 32531 100pF 5% NP0 50V 2190 4822 124 81151 22µF 50V
2106 2020 800 00191 3pF-11pF N450 100V 2191 4822 124 81151 22µF 50V
2107 4822 121 51319 1µF 10% 63V 2192 5322 122 31647 1nF 10% X7R 63V
2110 5322 122 32531 100pF 5% NP0 50V 2193 5322 122 31647 1nF 10% X7R 63V
2111 5322 122 32659 33pF 5% 50V 2194 5322 122 31647 1nF 10% X7R 63V
2120 5322 122 32658 22pF 5% 50V 2195 4822 124 81151 22µF 50V
2122 4822 122 33891 3,3nF 10% X7R 63V 2196 4822 122 33177 10nF 20% X7R 50V
2123 2238 861 18391 390pF 1% 50V 2197 4822 122 33177 10nF 20% X7R 50V
2124 5322 122 32654 22nF 10% X7R 63V
2125 2238 861 18561 560pF 1% 50V
2126 5322 122 31863 330pF 5% 63V
2127 4822 126 14076 220nF 25V
2128 4822 124 40248 10µF 20% 63V - RESISTORS -
2129 4822 124 41584 100µF 20% 10V 3101 4822 051 20333 33K 5% 0,1W
2130 4822 126 13482 470nF 80/20% 16V 3102 4822 117 10837 100K 1% 0.1W
2131 4822 126 13482 470nF 80/20% 16V 3103 4822 051 20822 8K2 5% 0,1W
2132 4822 126 13482 470nF 80/20% 16V 3104 4822 117 13577 330R 1% 1,25W
2133 4822 124 21913 1µF 20% 63V 3105 4822 117 11503 220R 1% 0.1W
2134 4822 126 13188 15nF 5% X7R 63V 3106 4822 051 20229 22R 5% 0,1W
2135 4822 126 13188 15nF 5% X7R 63V 3107 4822 051 20475 4M7 5% 0,1W
2136 4822 126 14076 220nF 80/20% 25V 3108 4822 117 11449 2K2 5% 0,1W
2137 4822 126 14076 220nF 80/20% 25V 3109 4822 117 11449 2K2 5% 0,1W
2138 4822 124 22652 2,2µF 20% 50V 3123 4822 051 20472 4K7 5% 0,1W
2139 4822 126 14236 15pF 5% 50V 3125 4822 117 10833 10K 1% 0,1W
2140 4822 126 13695 82pF 1% NP0 63V 3128 4822 117 11449 2K2 5% 0,1W
2141 4822 126 13838 100nF 80/20% Y5V 50V 3132 4822 051 20479 47R 5% 0,1W
2144 4822 126 13482 470nF 80/20% 16V 3134 4822 051 20223 22K 5% 0,1W
2145 4822 122 33575 220pF 5% NP0 63V 3137 4822 116 83933 15K 1% 0,1W
2146 4822 122 33575 220pF 5% NP0 63V 3141 4822 117 11148 56K 1% 0,1W
2147 4822 122 33575 220pF 5% NP0 63V 3142 4822 100 12159 100K 30%
2148 4822 122 33127 2,2nF 10% X7R 63V 3145 4822 117 11449 2K2 5% 0,1W
2150 4822 126 13838 100nF 80/20% Y5V 50V 3152 4822 051 20471 470R 5% 0,1W
2152 4822 126 12105 33nF 5% X7R 50V 3153 4822 051 20471 470R 5% 0,1W
2153 4822 126 13486 15pF 2% NP0 63V 3155 4822 051 20479 47R 5% 0,1W
2155 2020 800 00191 3pF-11pF N450 100V 3158 4822 051 20471 470R 5% 0,1W
2159 5322 122 32659 33pF 5% 50V 3159 4822 051 20471 470R 5% 0,1W
2163 4822 126 13838 100nF 80/20% Y5V 50V 3160 4822 051 20471 470R 5% 0,1W
2164 4822 126 13482 470nF 80/20% 16V 3161 4822 051 20223 22K 5% 0,1W
2165 4822 126 13838 100nF 80/20% Y5V 50V 3166 4822 051 20479 47R 5% 0,1W
2166 5322 122 31647 1nF 10% X7R 63V 3167 4822 051 20479 47R 5% 0,1W
2167 4822 122 33926 12pF 50V 3169 4822 051 20154 150K 5% 0,1W
2186 4822 124 40196 220µF 20% 16V 3170 4822 117 10837 100K 1% 0.1W
2187 4822 122 33177 10nF 20% X7R 50V 3180 4822 117 10833 10K 1% 0,1W
ELECTRICAL PARTSLIST - TUNER BOARD ECO6
- RESISTORS - - IC & TRANSISTORS -
3181 4822 051 10102 1K 2% 0,25W 7101 4822 209 90924 IC TEA5757H/V1
3186 4822 117 11448 180R 1% 0,1W 7102 4822 130 42131 Trans BF550
3187 4822 051 10102 1K 2% 0,25W 7104 4822 130 40855 Trans BC337
3188 4822 117 11449 2K2 5% 0,1W 7105 4822 130 40855 Trans BC337
3189 4822 051 20223 22K 5% 0,1W 7109 4822 130 60373 Trans BC856B
3190 4822 117 10833 10K 1% 0,1W 7111 5322 130 42755 Trans BC847C
3191 4822 051 20472 4K7 5% 0,1W 7122 5322 130 42755 Trans BC847C
3192 4822 051 20105 1M 5% 0,1W 7124 5322 130 42755 Trans BC847C
3193 4822 117 11449 2K2 5% 0,1W 7180 4822 130 60373 Trans BC856B
3194 4822 117 10837 100K 1% 0.1W 7181 5322 130 42755 Trans BC847C
3195 4822 051 20474 470K 5% 0,1W 7182 5322 130 42755 Trans BC847C
3196 4822 117 10833 10K 1% 0,1W 7183 5322 130 42755 Trans BC847C
4104 4822 051 20008 Jumper
4105 4822 051 20008 Jumper
4106 4822 051 20008 Jumper - MISCELLANEOUS -
4107 4822 051 20008 Jumper 1106 3140 114 50050 Ferrite Bar (For -/00/05)
4108 4822 051 20008 Jumper 1106 4822 526 10176 Ferrite Bar (For -/01/17)
4109 4822 051 20008 Jumper 1121 4822 267 10733 Connector 4P
4110 4822 051 20008 Jumper 1122 4822 267 10954 Connector 5P
- COILS & FILTERS - Note: Only these parts mentioned in the list are
normal service parts.
5104 4822 157 11269 Coil MW ANT
5104 2422 535 91074 Ind Fxd 185µH 5%
5105 4822 157 11271 Coil LW ANT
5109 4822 242 70665 Filter SFE10,7MS3-A
5110 4822 242 70665 Filter SFE10,7MS3-A
5111 2422 549 44023 Ind Var 450kHz
5112 4822 157 70302 Coil F7MCS-12216N
5114 4822 157 70302 Coil F7MCS-12216N
5119 4822 157 11443 Coil 2,4µH
5121 4822 242 10261 Crystal 75kHz
5122 2422 549 44108 Ind Var 796kHz
5123 2422 549 44108 Ind Var 796kHz
5130 4822 157 11843 Coil MD7B-01F
5131 4822 157 11843 Coil MD7B-01F
- DIODES -
6103 5322 130 34337 Diode BAV99
6105 4822 130 83075 Diode HN1V02H-B
6120 4822 130 83757 Diode BAS216
6130 4822 130 82833 Diode 1SV228
6131 4822 130 82833 Diode 1SV228
6181 5322 130 34337 Diode BAV99
6182 4822 130 83757 Diode BAS216
6183 9340 386 90115 Diode BZX284-C11
