Philips B line 346B1C User Manual

23
5. Technical Specifications
5.1 Resolution & Preset Modes
Maximum Resolution
3440x1440 @ 100 Hz (digital input)
Recommended Resolution
3440x1440 @ 60 Hz (digital input)
H. freq
(kHz)
Resolution V. freq
(Hz)
31.47 720x400 70.09
31.47 640x480 59.94
35.00 640x480 66.67
37.86 640x480 72.81
37.50 640x480 75.00
35.16 800x600 56.25
37.88 800x600 60.32
48.08 800x600 72.19
46.88 800x600 75.00
47.73 832x624 74.55
48.36 1024x768 60.00
56.48 1024x768 70.07
60.02 1024x768 75.03
44.77 1280x720 59.86
63.89 1280x1024 60.02
79.98 1280x1024 75.03
55.94 1440x900 59.89
65.29 1680x1050 59.95
89.48 1720x1440 59.97
67.50 1920x1080 60.00
113.22 1920x1080 99.93
67.17 2560x1080 59.98
113.24 2560x1080 99.94
44.41 3440x1440 29.99
88.82 3440x1440 59.97
150.97 3440x1440 99.98
Note
1. Please notice that your display
works best at native resolution of
3440x1440 @ 60Hz. For best display
quality, please follow this resolution
recommendation.
Recommended resolution
HDMI 2.0/DP/USB C:
3440x1440 @ 60Hz
If your display is not on the native
resolution when connecting to USB C
or DP port, please adjust resolution
to the optimal state: 3440x1440 @60
Hz from your PC.
2. The factory default setting
HDMI supports to the resolution
3440x1440 @ 60Hz.

Philips B line 346B1C Specifications

General

3D	No
DDC/CI	Yes
Haze rate	25 %
Panel type	VA
Pixel pitch	0.23175 x 0.23175 mm
Pixel density	110 ppi
Backlight type	W-LED
Display surface	Matt
Display diagonal	34 \
Screen curvature	1500 mm
Surface hardness	2H
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Adobe RGB coverage	90 %
Display technology	LCD
Native aspect ratio	21:9
Vertical scan range	48 - 100 Hz
Horizontal scan range	30 - 160 kHz
NTSC coverage (typical)	100 %
Screen curvature rating	1500R
Viewable size, vertical	333.7 mm
sRGB coverage (typical)	119 %
Contrast ratio (dynamic)	80000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	86.36 cm
Viewable size, horizontal	797.2 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	3440 x 1440
Dynamic contrast ratio marketing name	SmartContrast
LED indicators	Operation, Stand-by
Tilt angle range	-5 - 30 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
Delta E	2
MultiView	PIP/PBP mode, 2 x devices
Picture enhancement	SmartImage
Exterior finish type	Textured
Regulatory Approvals	CB; EPA; cETLus; FCC Class B; ICES-003; CE Mark; TUV/GS; TUV Ergo; SEMKO; CU-EAC; UKRAINIAN; TUV Eye Comfort certified
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Philips SmartUniformity	93 - 105 %
USB Power Delivery revision	3.0
Mean time between failures (MTBF)	70000 h
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.3 W
Power consumption (typical)	28.36 W
Power consumption (PowerSave)	34 W
NVIDIA G-SYNC	-
Component video sync	Separate sync
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Operating altitude	0 - 3658 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
RMS rated power	10 W
Cables included	HDMI, DisplayPort, USB Type-C, AC
Bundled software	SmartControl
Certification	CB, EPA, cETLus, FCC Class B, ICES-003, CE Mark, TUV/GS, TUV Ergo, SEMKO, CU-EAC, UKRAINIAN, TUV Eye Comfort certified
Product color	Black
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	Home
Package type	Box
Package depth	282 mm
Package width	930 mm
Package height	525 mm
Package weight	15320 g
Doesn't contain	Mercury (element), PVC/BFR
Sustainability certificates	ENERGY STAR, TCO, RoHS
HDCP version	1.4/2.2
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-B, USB Type-C
USB Power Delivery up to	90 W
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	250 mm
Height (with stand)	601 mm
Weight (with stand)	11490 g
Depth (without stand)	110 mm
Width (without stand)	807 mm
Height (without stand)	367 mm
Weight (without stand)	7790 g
