32
8. Troubleshooting & FAQs
Q11: What is Image Sticking, or Image
Burn-in, or After Image, or Ghost
Image in LCD panels?
Ans.: Uninterrupted display of still or
static images over an extended
period may cause "burn in",
also known as "after-imaging"
or "ghost imaging", on your
screen. "Burn-in", "after-
imaging", or "ghost imaging" is
a well-known phenomenon in
LCD panel technology. In most
cases, the "burned in" or "atter-
imaging" or "ghost imaging" will
disappear gradually over a period
of time after the power has been
switched off.
Always activate a moving screen
saver program when you leave
your display unattended.
Always activate a periodic screen
refresh application if your LCD
display will display unchanging
static content.
Warning
Failure to activate a screen saver, or
a periodic screen refresh application
may result in severe “burn-in” or “after-
image” or “ghost image” symptoms
that will not disappear and cannot be
repaired. The damage mentioned above
is not covered under your warranty.
Q12: Why is my Display not showing
sharp text, and is displaying
jagged characters?
Ans.: Your LCD display works best at its
native resolution of 3440x1440
@ 60 Hz. For best display, please
use this resolution.
Q13: How to unlock/lock my hot key?
Ans.: To lock the OSD, press and hold
the button while the
monitor is off and then press
button to turn the monitor on.
To un-lock the OSD, press and
hold the button while the
monitor is off and then press
button to turn the monitor on.
  
  
Q14: Where can I find Important
Information manual mentioned in
EDFU?
Ans.: Important Information manual
can be download on the Philips
website support page.
8.3 Multiview FAQs
Q1: How to listen to Audio,
independent of video?
Ans.: Normally the audio source is
linked to the main picture source.
If you want to change audio-
source input (for example: listen
to your MP3 player independently
regardless of the video source
input), you can press to enter
OSD menu. Select your preferred
[Audio Source] option from the
[Audio] main menu.
Please note that the next time
you turn on your Display, the
Display will by default select the
audio source you chose last time.
In case you want to change it
again, you need to go through the
above steps to select your new
preferred audio source, which
then will become the “default”
mode.
Q2: Why the sub-windows flickers
when I enable PBP.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Philips B line 346B1C and is the answer not in the manual?

Philips B line 346B1C Specifications

General IconGeneral
3DNo
DDC/CIYes
Haze rate25 %
Panel typeVA
Pixel pitch0.23175 x 0.23175 mm
Pixel density110 ppi
Backlight typeW-LED
Display surfaceMatt
Display diagonal34 \
Screen curvature1500 mm
Surface hardness2H
Anti-glare screenAlways gives an optimal view, even in direct sunlight.
Adobe RGB coverage90 %
Display technologyLCD
Native aspect ratio21:9
Vertical scan range48 - 100 Hz
Horizontal scan range30 - 160 kHz
NTSC coverage (typical)100 %
Screen curvature rating1500R
Viewable size, vertical333.7 mm
sRGB coverage (typical)119 %
Contrast ratio (dynamic)80000000:1
Contrast ratio (typical)3000:1
Display number of colors16.7 million colors
Display diagonal (metric)86.36 cm
Viewable size, horizontal797.2 mm
Display brightness (typical)300 cd/m²
Supported graphics resolutions3440 x 1440
Dynamic contrast ratio marketing nameSmartContrast
LED indicatorsOperation, Stand-by
Tilt angle range-5 - 30 °
Cable lock slot typeKensington
Panel mounting interface100 x 100 mm
On Screen Display (OSD) languagesCHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
Delta E2
MultiViewPIP/PBP mode, 2 x devices
Picture enhancementSmartImage
Exterior finish typeTextured
Regulatory ApprovalsCB; EPA; cETLus; FCC Class B; ICES-003; CE Mark; TUV/GS; TUV Ergo; SEMKO; CU-EAC; UKRAINIAN; TUV Eye Comfort certified
Ethernet LAN data rates10, 100, 1000 Mbit/s
Philips SmartUniformity93 - 105 %
USB Power Delivery revision3.0
Mean time between failures (MTBF)70000 h
AC input voltage100 - 240 V
Power supply typeInternal
AC input frequency50 - 60 Hz
Energy efficiency scaleA to G
Power consumption (standby)0.3 W
Power consumption (typical)28.36 W
Power consumption (PowerSave)34 W
NVIDIA G-SYNC-
Component video syncSeparate sync
Mac operating systems supportedMac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supportedWindows 10, Windows 7, Windows 8, Windows 8.1
Operating altitude0 - 3658 m
Non-operating altitude0 - 12192 m
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)20 - 80 %
RMS rated power10 W
Cables includedHDMI, DisplayPort, USB Type-C, AC
Bundled softwareSmartControl
CertificationCB, EPA, cETLus, FCC Class B, ICES-003, CE Mark, TUV/GS, TUV Ergo, SEMKO, CU-EAC, UKRAINIAN, TUV Eye Comfort certified
Product colorBlack
Heavy metals freeHg (mercury), Pb (lead)
Market positioningHome
Package typeBox
Package depth282 mm
Package width930 mm
Package height525 mm
Package weight15320 g
Doesn't containMercury (element), PVC/BFR
Sustainability certificatesENERGY STAR, TCO, RoHS
HDCP version1.4/2.2
USB hub version3.2 Gen 1 (3.1 Gen 1)
DisplayPort version1.2
Headphone connectivity3.5 mm
USB upstream port typeUSB Type-B, USB Type-C
USB Power Delivery up to90 W
VGA (D-Sub) ports quantity0
USB Type-A downstream ports quantity4
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)250 mm
Height (with stand)601 mm
Weight (with stand)11490 g
Depth (without stand)110 mm
Width (without stand)807 mm
Height (without stand)367 mm
Weight (without stand)7790 g
