28
7. Customer care and warranty
7.2 Customer Care & Warranty
For warranty coverage information and additional support requirements valid for your
region, please visit www.philips.com/support website for details or contact your local
Philips Customer Care Center.
For extended warranty, if you would like to extend your general warranty period, an
Out of Warranty service package is offered via our Certified Service Center.
For Warranty Period please refer to Warranty Statement in Important Information
Manual.
If you wish to make use of this service, please be sure to purchase the service within 30
calendar days of your original purchase date. During the extended warranty period, the
service includes pickup, repair and return service, however the user will be responsible
for all costs accrued.
If the Certified Service Partner cannot perform the required repairs under the offered
extended warranty package, we will find alternative solutions for you, if possible, up to
the extended warranty period you have purchased.
Please contact our Philips Customer Service Representative or local contact center (by
Consumer care number) for more details.
Philips Customer Care Center number listed below.
• Local
Standard
Warranty
Period
• Extended Warranty
Period
• Total Warranty Period
• Depend
on different
Regions
• + 1 Year • Local Standard warranty period +1
• + 2 Years • Local Standard warranty period
+2
• + 3 Years • Local Standard warranty period
+3
**Proof of original purchase and extended warranty purchase required.
Note
1. Please refer to important information manual for regional service hotline, which is
available on the Philips website support page.
2. Spare parts are available for use in the repair of the product for minimum three-
year from your original purchase date or 1 year after the end of production,
whichever is longer.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Philips B line 346B1C and is the answer not in the manual?

Philips B line 346B1C Specifications

General IconGeneral
3DNo
DDC/CIYes
Haze rate25 %
Panel typeVA
Pixel pitch0.23175 x 0.23175 mm
Pixel density110 ppi
Backlight typeW-LED
Display surfaceMatt
Display diagonal34 \
Screen curvature1500 mm
Surface hardness2H
Anti-glare screenAlways gives an optimal view, even in direct sunlight.
Adobe RGB coverage90 %
Display technologyLCD
Native aspect ratio21:9
Vertical scan range48 - 100 Hz
Horizontal scan range30 - 160 kHz
NTSC coverage (typical)100 %
Screen curvature rating1500R
Viewable size, vertical333.7 mm
sRGB coverage (typical)119 %
Contrast ratio (dynamic)80000000:1
Contrast ratio (typical)3000:1
Display number of colors16.7 million colors
Display diagonal (metric)86.36 cm
Viewable size, horizontal797.2 mm
Display brightness (typical)300 cd/m²
Supported graphics resolutions3440 x 1440
Dynamic contrast ratio marketing nameSmartContrast
LED indicatorsOperation, Stand-by
Tilt angle range-5 - 30 °
Cable lock slot typeKensington
Panel mounting interface100 x 100 mm
On Screen Display (OSD) languagesCHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
Delta E2
MultiViewPIP/PBP mode, 2 x devices
Picture enhancementSmartImage
Exterior finish typeTextured
Regulatory ApprovalsCB; EPA; cETLus; FCC Class B; ICES-003; CE Mark; TUV/GS; TUV Ergo; SEMKO; CU-EAC; UKRAINIAN; TUV Eye Comfort certified
Ethernet LAN data rates10, 100, 1000 Mbit/s
Philips SmartUniformity93 - 105 %
USB Power Delivery revision3.0
Mean time between failures (MTBF)70000 h
AC input voltage100 - 240 V
Power supply typeInternal
AC input frequency50 - 60 Hz
Energy efficiency scaleA to G
Power consumption (standby)0.3 W
Power consumption (typical)28.36 W
Power consumption (PowerSave)34 W
NVIDIA G-SYNC-
Component video syncSeparate sync
Mac operating systems supportedMac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supportedWindows 10, Windows 7, Windows 8, Windows 8.1
Operating altitude0 - 3658 m
Non-operating altitude0 - 12192 m
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)20 - 80 %
RMS rated power10 W
Cables includedHDMI, DisplayPort, USB Type-C, AC
Bundled softwareSmartControl
CertificationCB, EPA, cETLus, FCC Class B, ICES-003, CE Mark, TUV/GS, TUV Ergo, SEMKO, CU-EAC, UKRAINIAN, TUV Eye Comfort certified
Product colorBlack
Heavy metals freeHg (mercury), Pb (lead)
Market positioningHome
Package typeBox
Package depth282 mm
Package width930 mm
Package height525 mm
Package weight15320 g
Doesn't containMercury (element), PVC/BFR
Sustainability certificatesENERGY STAR, TCO, RoHS
HDCP version1.4/2.2
USB hub version3.2 Gen 1 (3.1 Gen 1)
DisplayPort version1.2
Headphone connectivity3.5 mm
USB upstream port typeUSB Type-B, USB Type-C
USB Power Delivery up to90 W
VGA (D-Sub) ports quantity0
USB Type-A downstream ports quantity4
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)250 mm
Height (with stand)601 mm
Weight (with stand)11490 g
Depth (without stand)110 mm
Width (without stand)807 mm
Height (without stand)367 mm
Weight (without stand)7790 g
