Philips BDP7502 - Unit Functional Overview; Top and Front Panel Controls; Rear Panel Connections

EN 9
3. FUNCTIONAL OVERVIEW
3.1. Top / front panel
1 5 6
3* 42
Top
Front
* The unit can also be turned on by pressing this button.
1. Disc tray
2. Power-on indicator
3.
(OPEN/CLOSE) button*
4.
(POWER) button
5. Infrared sensor window
6. USB input
CautionC
• Do not connect any device other than USB memory stick or USB card reader into the USB input. (e.g. PC,
external HDD, digital camera, keyboard, mouse, etc.)
• When connecting a USB memory stick, connect it directly to the USB input. Do not use a USB extension cable.
3.2. Rear panel
1 2 3 4 5
1. AC power cord
2. LAN terminal
3. HDMI OUT jack
4. HDMI OUT (AUDIO) jack
5. OPTICAL jack
CautionC
• Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent
damage to the unit.
• This unit does not have a TV RF modulator.
