Use the barcode scanner (DPM8500
only)
The barcode module allows barcode scanning from a distance of
up to 25 cm (10 inches) and supports barcode information with
up to 30 digits.
Add barcode information to a file
1
While the recorder is in stop mode, press F1 (Scan) and
scan the barcode.
X When a barcode is recognized, the device will beep and
the barcode information is displayed.
2
Press F2 (OK) to confirm the barcode input.
X The device returns to the stop mode.
Display barcode information
To display previously recorded barcode information:
1
While the recorder is in stop mode, press F2 (Menu) and
select File > File information.
Overwrite barcode information
1
While the recorder is in stop mode, press F1 (Scan) and
scan the barcode.
X When a barcode is recognized, the device will beep and
the old and the new barcode information is displayed.
2
Press F2 (OK) to confirm the new barcode information and
to overwrite the old barcode information.
X The device returns to the stop mode.
