Basic connections:
Video•
Audio•
Optional connections:
Route audio to other devices:•
Digital amplifier/receiver•
Analog stereo system•
USB flash drive•
Note
Refer to the type plate at the back or bottom of the •
product for identification and supply ratings.
Before you make or change any connections, ensure that
•
all the devices are disconnected from the power outlet.
Connect audio/video cables
Select the best video connection that TV can
support.
• Option 1: Connect to component video jacks
(for a standard TV or Progressive Scan TV).
• Option 2: Connect to scart jack (for a
standard TV).
• Option 3: Connect to video (CVBS) jack (for a
standard TV).
Note
You must connect this product directly to a TV. •
Option 1: Connect to component video
jacks
1 Connect the component video cables to:
the • Y Pb Pr jacks on this product.
the COMPONENT VIDEO input jacks •
on the TV.
2 Connect the audio cables to:
Pb
Y
Pr
AUDIO OUT
During photo slideshow, switch photo •
display between the fun mode (color)
and the simple mode (black and white).
For VCD and SVCD: turn on or off PBC •
(playback control).
d
Navigate the menus.•
Search fast-forward (•
) or fast-backward
( ).
Search slow-forward (• ) or slow-
backward ( ).
e
BACK
Return to the previous display menu.•
f
/
Skip to the previous or next title, chapter, •
or track.
g
Switch to the USB mode.•
h Numeric buttons
Select an item to play.•
i SUBTITLE
Select a subtitle language on a disc.•
j
ZOOM
Fit the picture display to the TV screen.•
Zoom the picture in or out.•
k REPEAT
Select various repeat play modes.•
l REPEAT A-B
Repeat play for a specific section.•
m AUDIO/CREATE MP3
Select an audio language or channel on •
a disc.
Access the menu of creating MP3 files.•
n
Stop play.•
o
Start, pause or resume disc play.•
p
INFO
For discs: access the play options or •
display the current disc status.
For slideshows: display a thumbnail view •
of photo files.
q OK
Confirm an entry or selection.•
r SETUP
Access or exit the setup menu.•
3 Connect
All audio/video cables are sold separately.
Make the following connections to use this product.
EN
