Philips EP5345/10 - Coffee Grinder Adjustment; Service Center Grinder Adjustment

PHI 5000 LATTE GO / GO+ 08 DISASSEMBLY
5/7
For a standard adjustment, both markings must be
aligned.
7.5. Coffee grinder adjustment
Adjustment by a service center
-
+
e grinding adjustment can be set by the
user pressing and turning the grinder adjust-
ment knob
To adjust grinding further, the engineer can work directly on the coee grinder by pressing and turning the ring nut
(C) shown. (clockwise + to increase the particle size of the coee and anticlockwise - to decrease it).
If there are any remains of coee powder between the two grinding blades it is recommended to tighten by max.
two marks at a time.
Lastly, move the arrow (A) on the adjustment knob to the center of the adjustment dots on the cover (B) ascertain
that the center line of the “PRESS” (D) is in correspondence of the n (E).
B
A
+
-
C
D
E
