Philips EP5345/10 - Central Plate Component Removal

PHI 5000 LATTE GO / GO+ 08 DISASSEMBLY
6/7
When reassembling the assembly to be
careful to correctly position.
Slide out the fork
as illustrated
7.6. Carafe connection / hot steam water dispenser
7.7. Central plate
unscrew the screws shown
Lift up the center plate
Remove the
cover using the
screwdriver as in
the photo.
