ErgoLine D330/D340
Customer Engineer Manual
Page 2-16
Key
= Marking on the terminal (numbers in italics are keypad
key numbers)
Test
= Indication on LCD during the keyboard test in the
maintenance menu
SOPHO
= Function key numbering for downloading from SOPHO iS
in function key menus.
F
IGURE
2-4. DSS K
EY
N
UMBERING
DSS 1 Keys DSS 2 Keys DSS 3 Keys
Key 1-1
Test 2/1
SOPHO 12
Key 2-1
Test 3/1
SOPHO 100
Key 3-1
Test 4/1
SOPHO 114
Key 1-2
Test 2/4
SOPHO 13
Key 2-2
Test 3/4
SOPHO 101
Key 3-2
Test 4/4
SOPHO 115
Key 1-3
Test 2/7
SOPHO 14
Key 2-3
Test 3/7
SOPHO 102
Key 3-3
Test 4/7
SOPHO 116
Key 1-4
Test 2/10
SOPHO 15
Key 2-4
Test 3/10
SOPHO 103
Key 3-4
Test 4/10
SOPHO 117
Key 1-5
Test 2/13
SOPHO 16
Key 2-5
Test 3/13
SOPHO 104
Key 3-5
Test 4/13
SOPHO 118
Key 1-6
Test 2/16
SOPHO 17
Key 2-6
Test 3/16
SOPHO 105
Key 3-6
Test 4/16
SOPHO 119
Key 1-7
Test 2/19
SOPHO 18
Key 2-7
Test 3/19
SOPHO 106
Key 3-7
Test 4/19
SOPHO 120
Key 1-8
Test 2/22
SOPHO 19
Key 2-8
Test 3/22
SOPHO 107
Key 3-8
Test 4/22
SOPHO 121
Key 1-9
Test 2/0
SOPHO 20
Key 2-9
Test 3/0
SOPHO 108
Key 3-9
Test 4/0
SOPHO 122
Key 1-10
Test 2/3
SOPHO 21
Key 2-10
Test 3/3
SOPHO 109
Key 3-10
Test 4/3
SOPHO 123
Key 1-11
Test 2/6
SOPHO 22
Key 2-11
Test 3/6
SOPHO 110
Key 3-11
Test 4/6
SOPHO 124
Key 1-12
Test 2/9
SOPHO 23
Key 2-12
Test 3/9
SOPHO 111
Key 3-12
Test 4/9
SOPHO 125
Key 1-13
Test 2/12
SOPHO 24
Key 2-13
Test 3/12
SOPHO 112
Key 3-13
Test 4/12
SOPHO 126
Key 1-14
Test 2/15
SOPHO 25
Key 2-14
Test 3/15
SOPHO 113
Key 3-14
Test 4/15
SOPHO 127
Note
: Keys at the DSS 2 and DSS 3 are not downloadable in the CPU package
SSW 805.
