ErgoLine D330/D340
Customer Engineer Manual
Page 2-30
T
ABLE
2-5. S
TATIC
I
NTERFACE
S
PECIFICATION
Connector 6-pin RJ11
Input Level -
0
≤
0.9V
Input Level -
1
≥
3.7V
Input Impedance
10 k
Ω
(pull-up)
Output Impedance
1.5 k
Ω ±
10%
Impedance +5V STAT
100
Ω
T
ABLE
2-6. S
TATIC
I
NTERFACE
P
IN
C
ONFIGURATION
SIGNAL PIN DESCRIPTION
+5V STAT 1 +5V supply voltage
Busy 2 Busy indication
Door 3 Door opener
FS 4 Foot switch
GND 5 Earth
Ring 6 Second bell
