22
English
TECHNICAL DATA
Subject to modification without notice.
General
Power consumption (FR 740, MX 740) ............................210 W
Power consumption (FR 760) ...........................................255 W
Standby power consumption............................................< 2 W
Dimensions, w × h × d ............................435 × 135 × 350 mm
Weight (FR 740, MX 740) .................................................8.6 kg
Weight (FR 760) ................................................................9.4 kg
Amplifier part (0.7 % THD, 6 Ω, 1 kHz)
Output power, stereo mode (FR 740, MX 740) (DIN)...2 × 60 W
Output power, surround mode (FR 740, MX 740)
Front ......................................................................2 × 60 W
Center ..........................................................................60 W
Surround................................................................2 × 60 W
Output power, stereo mode (FR 760) (DIN)...............2 × 100 W
Output power, surround mode (FR 760)
Front ....................................................................2 × 100 W
Center ........................................................................100 W
Surround..............................................................2 × 100 W
Bass ..................................................................±9 dB at 100 Hz
Treble ................................................................±9 dB at 10 kHz
Loudness....+6 dB at 100 Hz (-30 dB); +3 dB at 10 kHz (-30 dB)
Total harmonic distortion.........................0.05 % at 1 kHz, 5 W
Frequency response ..................................20–20,000 Hz, ±1 dB
S/N ratio ........................................................................≥ 82 dB
Stereo separation (1 kHz) ..............................................≥ 45 dB
Crosstalk (1 kHz) ...........................................................≤ -65 dB
Inputs
Linear inputs.......................................................250 mV/47 kΩ
6 CH ....................................................................250 mV/40 kΩ
Front AV (FR 760 only) ........................................250 mV/22 kΩ
Outputs
Power supply AC outlet (switched).............totally max. 100 W
Linear outputs.......................................................250 mV/1 kΩ
Subwoofer pre-out....................................................0.8 V/1 kΩ
Center pre-out...........................................................0.8 V/1 kΩ
Headphones....................................8–600 Ω (3 V e.m.f., 60 Ω)
Speakers ...........................................................................≥ 6 Ω
Tuner part
Wave range
FM..............................................................87.5–108.0 MHz
MW...............................................................531–1,602 kHz
LW....................................................................153–279 kHz
Sensitivity
Stereo FM ..................................................................41 dBf
Mono FM....................................................................15 dBf
Total harmonic distortion
Stereo FM ...................................................................0.3 %
Mono FM...................................................................0.85 %
Frequency response ...................................63–12,500 Hz ±1 dB
S/N ratio
Stereo FM....................................................................55 dB
Mono FM.....................................................................60 dB
Channel separation.............................................35 dB at 1 kHz
Subject to modification without notice.
Front speakers
Impedance............................................................................6 Ω
Frequency range ...................................................40–20,000 Hz
Power handling capacity....................................................60 W
Power handling capacity – peak .....................................120 W
Sensitivity..........................................................................89 dB
Drivers ....................................1 × 5
1
⁄
4" woofers, 1 × 2" tweeter
Passive radiator .................................................1 × 6
1
⁄
2" woofer
Crossover frequencies ..................................................4,000 Hz
Dimensions, h × w × d ............................421 × 219 × 191 mm
Weight..................................................................approx. 2.5 kg
Rear speakers
Impedance............................................................................6 Ω
Frequency range .................................................100–20,000 Hz
Power handling capacity....................................................60 W
Power handling capacity – peak .....................................120 W
Sensitivity..........................................................................89 dB
Drivers..............................................................1 × 4" full range
Passive radiator .................................................1 × 6
1
⁄
2" woofer
Crossover frequencies ..................................................4,500 Hz
Dimensions, h × w × d ..............................179 × 181 × 92 mm
Weight.........................................................approx. 0.7 kg each
Center speaker
Impedance............................................................................6 Ω
Frequency range ...................................................75–20,000 Hz
Power handling capacity....................................................60 W
Power handling capacity – peak .....................................120 W
Sensitivity..........................................................................89 dB
Drivers ......................................2 × 4" woofers, 1 × 2" tweeter
Crossover frequencies ..................................................4,500 Hz
Dimensions, h × w × d ............................131 × 435 × 122 mm
Weight..................................................................approx. 1.6 kg
Speakers (supplied with MX 740 only)Receiver
