7B-4 7B-4
PCS 102 353
ELECTRICAL PARTSLIST - ECO5 TUNER BOARD
MISCELLANEOUS
TRANSISTORS & ICs
1101 482226731505 Antenna Socket 300R only in /17
1102 482226710283 Antenna Socket 75R only in /01
2101 532212232531 100PF 5%NP0 50V only in /01
2101 482212613692 47PF 1% NP0 63V only in /17
2102 482212233177 10NF 20% X7R 50V
2103 532212234123 1NF10%X7R 50V
2104 482212233195 100PF 10% 50V
2106 482212560101 3P0-11P N450 100V
2107 482212151319 1UF 10% 63V
2120 532212232658 22PF 5% 50V
2125 482212151381 560PF 5% 400V
2126 532212231863 63V 330PF PM5
2127 482212613473 220NF80-20% 50V
2128 482212441579 10UF 20% 50V
2129 482212441584 100UF 20% 10V
2130 482212611585 22NF+80-20% Y5V 25V
2131 482212613482 470NF80/20% 16V
2132 482212613482 470NF80/20% 16V
2133 482212440242 1UF20% 63V
2134 482212613188 15NF 5% X7R 63V only in /01
2134 532212232654 22NF10%X7R 63V only in /17
2135 482212440746 0,22UF20% 63V
2136 482212613188 15NF 5% X7R 63V only in /01
2136 532212232654 22NF10%X7R 63V only in /17
2137 482212440746 0,22UF20% 63V
2138 482212441576 2,2UF 20% 50V
2139 482212614236 50V 15P 5%
2141 482212610002 100NF20%Y5V 25V
2142 482212610002 100NF20%Y5V 25V
2143 482212613473 220NF80-20% 50V
2144 482212440242 1UF20% 63V
2145 482212233575 220PF 5% NP0 63V
2146 482212233575 220PF 5% NP0 63V
2147 482212233575 220PF 5% NP0 63V
2148 482212611585 22NF+80-20% Y5V 25V
2149 532212232654 22NF10%X7R 63V
2150 482212231947 100NF20%Y5V 63V
2152 482212612105 50V 33NF PM5
2153 482212232504 15PF 2% NP0 50V 1206
2155 482212560101 3P0-11P N450 100V
2159 532212232659 33PF 5% 50V
2160 532212232654 22NF10%X7R 63V
2164 482212613482 470NF80/20% 16V
2165 482212610002 100NF20%Y5V 25V
2166 532212234123 1NF10%X7R 50V
2167 482212232139 12PF 2%NP0 63V
2168 482212613695 82PF 1% NP0 63V
CAPACITORS
3101 482205120333 33K00 5% 0,1W
3102 482205120104 100K00 5% 0,1W
3103 482211710965 18K 1% 0,1W
3104 482211711448 180R 1% 0,1W
3105 482211683872 220R 5% 0,5W
3110 482211652195 47E 5% 0,5W
3120 482205120008 0R00 JUMP. (0805)
3132 482211652195 47E 5% 0,5W
3134 482205120223 22K00 5% 0,1W
3141 482211711148 56K 1% 0,1W
3142 482210011163 100K 30%LIN 0,1W
3145 482211711449 2K2 1% 0,1W
3146 482205120229 22R 5% 0,1W
3152 482211683883 470R 5% 0,5W
3153 482205120471 470R 5% 0,1W
3154 482211683868 150R 5% 0,5W
3155 482205120471 470R 5% 0,1W
3156 482205120104 100K 5% 0,1W only in /01
3158 482211683883 470R 5% 0,5W
3159 482211683883 470R 5% 0,5W
3160 482211683883 470R 5% 0,5W
3161 482211683883 470R 5% 0,5W
3167 482211711503 220R 1% 0.1W
3169 482205120154 150K 5% 0,1W
3170 482211652234 100K 5% 0,5W
3171 482211652219 330E 5% 0,5W
4101 482205120008 0R00 JUMP. (0805)
4102 482205120008 0R00 JUMP. (0805)
4103 482205120008 0R00 JUMP. (0805)
4104 482205120008 0R00 JUMP. (0805)
4105 482205120008 0R00 JUMP. (0805)
4106 482205120008 0R00 JUMP. (0805)
4108 482205120008 0R00 JUMP. (0805)
4111 482205120008 0R00 JUMP. (0805)
4120 482205120008 0R00 JUMP. (0805)
4150 482205110008 0R00 5% 0,25W
4152 482205110008 0R00 5% 0,25W
4153 482205110008 0R00 5% 0,25W
4154 482205110008 0R00 5% 0,25W
4157 482205110008 0R00 5% 0,25W
4158 482205110008 0R00 5% 0,25W
4159 482205110008 0R00 5% 0,25W
5102 482215771634 MW RF COIL
5109 482224270665 SFE 10,7MHz
5110 482224270665 SFE 10,7MHz
5111 482215860511 AM-IF Filter 10,7MHz
5112 482215770302 AM-IF Filter 10,7MHz
5114 482215770302 AM-IF Filter 10,7MHz
5119 482215711443 Disciminator 10,7MHz
RESISTORS
COILS & FILTERS
5121 482224210261 Quartz 75kHz
5123 482215760517 Osc Coil MW
5130 482215630947 RF-Coil 1,5T
5131 482215630947 RF-Coil 1,5T
6103 482213030621 1N4148
6104 482213030621 1N4148
6105 482213083075 HN1V02H-B
6106 482213030621 1N4148
6107 482213034488 BZX79-B11
6120 482213030621 1N4148 only in /17
6130 482213082833 1SV228
6131 482213082833 1SV228
7101 482220990924 TEA5757H/V1
7102 482213060093 2SA838B
7111 532213042136 BC848C
DIODES
