ELECTRICAL PARTS LIST - FRONT CONTROL BOARD
5-6 5-6
MISCELLANEOUS
ELECTRICAL PARTS LIST - FRONT CONTROL BOARD
1602 4822 265 11535 Flex Connector 8P
1603 4822 265 11208 Flex Connector 10P
1650 4822 276 13775 Tact Switch
1651 4822 276 13775 Tact Switch
1652 4822 276 13775 Tact Switch
1653 4822 276 13775 Tact Switch
1654 4822 276 13775 Tact Switch
1655 4822 276 13775 Tact Switch
1656 4822 276 13775 Tact Switch
1657 4822 276 13775 Tact Switch
1658 4822 276 13775 Tact Switch
1659 4822 276 13775 Tact Switch
1661 4822 276 13775 Tact Switch /22
1663 4822 276 13775 Tact Switch
1664 4822 276 13775 Tact Switch
1665 4822 276 13775 Tact Switch
1666 4822 276 13775 Tact Switch
1667 4822 276 13775 Tact Switch
1669 4822 276 13775 Tact Switch
1670 4822 276 13775 Tact Switch
1671 4822 276 13775 Tact Switch
1672 4822 276 13775 Tact Switch
1673 4822 276 13775 Tact Switch
1674 4822 276 13775 Tact Switch
1675 4822 276 13775 Tact Switch /22
1690 2422 129 16385 Rotary Encoder 12P
1800 4822 265 11207 Flex Connector 6P
1801 4822 276 13775 Tact Switch
1802 4822 276 13775 Tact Switch
1803 4822 276 13775 Tact Switch
1804 4822 276 13775 Tact Switch
1805 4822 276 13775 Tact Switch
1840 4822 267 10731 Flex Connector 6P
CAPACITORS
2606 5322 126 11583 10nF 10% 50V
2607 5322 126 11583 10nF 10% 50V
2608 4822 122 31765 100pF 2% 63V
2613 4822 122 31765 100pF 2% 63V
2615 4822 124 12233 47µF 20% 25V
2622 4822 126 14305 100nF 10% 16V
2623 4822 126 14305 100nF 10% 16V
2800 4822 122 31765 100pF 2% 63V
2840 4822 122 31765 100pF 2% 63V
2841 4822 124 22651 1µF 20% 50V
2842 4822 122 31765 100pF 2% 63V
2843 4822 122 31765 100pF 2% 63V
2844 4822 122 31765 100pF 2% 63V
2860 4822 124 81286 47µF 20% 16V
2861 4822 126 14238 2,2nF 50V
2862 3198 017 34730 47nF 16V
3606 4822 051 30103 10k 5% 0,062W
3607 4822 051 30103 10k 5% 0,062W
3610 4822 051 30151 150R 5% 0,062W
3611 4822 051 30221 220R 5% 0,062W
3612 4822 051 30271 270R 5% 0,062W
3613 4822 051 30391 390R 5% 0,062W
3614 4822 051 30561 560R 5% 0,062W
3615 4822 117 12968 820R 5% 0,62W
3616 4822 117 11817 1k2 1% 1/16W
3617 4822 117 12903 1k8 1% 0,063W
3618 4822 116 52263 2k7 5% 0,5W
3619 4822 051 30472 4k7 5% 0,062W
3620 4822 051 30103 10k 5% 0,062W
3621 4822 051 30121 120R 5% 0,062W
3622 4822 051 30121 120R 5% 0,062W
3623 4822 051 30121 120R 5% 0,062W
3624 4822 051 30121 120R 5% 0,062W
3630 4822 051 30151 150R 5% 0,062W
3631 4822 051 30221 220R 5% 0,062W
3632 4822 051 30271 270R 5% 0,062W
3633 4822 051 30391 390R 5% 0,062W
3634 4822 051 30561 560R 5% 0,062W
3635 4822 117 12968 820R 5% 0,62W
3636 4822 117 11817 1k2 1% 1/16W
3637 4822 117 12903 1k8 1% 0,063W
3638 4822 051 30272 2k7 5% 0,062W
3639 4822 051 30472 4k7 5% 0,062W
3640 4822 051 30103 10k 5% 0,062W
3646 4822 051 30181 180R 5% 0,062W
3651 4822 051 30221 220R 5% 0,062W
3652 4822 051 30221 220R 5% 0,062W
3653 4822 051 30271 270R 5% 0,062W
3654 4822 051 30121 120R 5% 0,062W
3655 4822 051 30102 1k 5% 0,062W
3800 4822 116 83872 220R 5% 0,5W
3801 4822 116 83872 220R 5% 0,5W
3802 4822 116 83872 220R 5% 0,5W
3803 4822 051 30561 560R 5% 0,062W
3804 4822 051 30391 390R 5% 0,062W
3805 4822 051 30271 270R 5% 0,062W
3806 4822 051 30221 220R 5% 0,062W
3807 4822 051 30151 150R 5% 0,062W
3841 4822 117 12925 47k 1% 0,063W
3842 4822 117 13632 100k 1% 0,62W
3843 4822 051 30102 1k 5% 0,062W
3844 4822 117 12902 8k2 1% 0,063W
3845 4822 117 11817 1k2 1% 1/16W
3846 4822 116 52283 4k7 5% 0,5W
3847 4822 116 83872 220R 5% 0,5W
3848 4822 051 30471 470R 5% 0,062W
3849 4822 116 83868 150R 5% 0,5W
3850 4822 051 30391 390R 5% 0,062W
3851 4822 051 30181 180R 5% 0,062W
3860 4822 051 30101 100R 5% 0,062W
3861 4822 051 30103 10k 5% 0,062W
3862 4822 050 11002 1k 1% 0,4W
4500 4822 051 30008 0R Jumper 0603
4600 4822 051 30008 0R Jumper 0603
4601 4822 051 30008 0R Jumper 0603
4602 4822 051 30008 0R Jumper 0603
4603 4822 051 30008 0R Jumper 0603
4604 4822 051 30008 0R Jumper 0603
4605 4822 051 30008 0R Jumper 0603
4606 4822 051 30008 0R Jumper 0603
4607 4822 051 30008 0R Jumper 0603
4627 4822 051 30008 0R Jumper 0603
4628 4822 051 30008 0R Jumper 0603
4843 4822 051 30008 0R Jumper 0603
4845 4822 051 30008 0R Jumper 0603
COILS & FILTERS
5600 3139 110 52720 METER VU P-47SI-B BLUE
DIODES
6602 4822 130 30621 1N4148
6603 4822 130 10791 LTL-1CHGE
6604 4822 130 10791 LTL-1CHGE
6605 4822 130 10791 LTL-1CHGE
6606 4822 130 10791 LTL-1CHGE
6610 4822 130 10791 LTL-1CHGE
6611 4822 130 10791 LTL-1CHGE
6612 4822 130 82978 LTL-1CHPE
6613 4822 130 10791 LTL-1CHGE
6623 9322 153 37676 LB3333RT-E7898
6802 4822 130 10791 LTL-1CHGE
6803 4822 130 10791 LTL-1CHGE
6804 4822 130 10791 LTL-1CHGE
6840 4822 130 30621 1N4148
6841 4822 130 30621 1N4148
6842 9322 153 37676 LB3333RT-E7898
6843 4822 130 82978 LTL-1CHPE
6844 4822 130 11589 LTL-1CHAE
TRANSISTORS & INTEGRATED CIRCUITS
7602 5322 130 60159 BC847B
7800 9322 155 22667 TSOP2236ZC1
7841 5322 130 60159 BC847B
7842 4822 130 60373 BC857B
7843 5322 130 60159 BC847B
7844 5322 130 60159 BC847B
7845 4822 130 60373 BC857B
Note : Only the parts mentioned in this list are normal
service spare parts.
RESISTORS
