Philips FW-C700 - Location of Printed Circuit Boards; Version Variations

1-2
LOCATION OF PRINTED CIRCUIT BOARDS
/21
Aux in /CDR in x
Line Out x
Surround Out
Subwoofer Out
Digital Out x
Matrix Surround
CD Text
Dolby B
RDS
News
Dolby Pro Logic (DPL)
Incredible Surround x
Karaoke Features
Voltage Selector x
ECO Power Standby (Clock Display Off)
ECO6 Tuner Board - Systems Non-Cenelec x
ECO6 Tuner Board - Systems Cenelec
Center/Surround Channel
VERSION VARIATIONS:
Type /Versions: FW-C700
Features &
Board in used:
HEADPHONE
BOARD
ETF7
BOARD
MAINS
BOARD
POWER
BOARD
MAINS SOCKET
BOARD
TUNER
BOARD
KEY-CDC BOARD
FRONT
DISPLAY
BOARD
IR-EYE
BOARD
VU
METER
BOARD
FRONT CONTROL
BOARD
AF9
BOARD
CD
BOARD
