Philips FW-C700 - Page 18

5-6 5-6
ELECTRICAL PARTS LIST - FRONT CONTROL BOARD
RESISTORS
3860 4822 051 30101 100R 5% 0,062W
3861 4822 051 30103 10k 5% 0,062W
3862 4822 050 11002 1k 1% 0,4W
4500 4822 051 30008 0R Jumper 0603
4600 4822 051 30008 0R Jumper 0603
4601 4822 051 30008 0R Jumper 0603
4602 4822 051 30008 0R Jumper 0603
4603 4822 051 30008 0R Jumper 0603
4604 4822 051 30008 0R Jumper 0603
4605 4822 051 30008 0R Jumper 0603
4606 4822 051 30008 0R Jumper 0603
4607 4822 051 30008 0R Jumper 0603
4627 4822 051 30008 0R Jumper 0603
4628 4822 051 30008 0R Jumper 0603
4843 4822 051 30008 0R Jumper 0603
4845 4822 051 30008 0R Jumper 0603
COILS & FILTERS
5600 3139 110 52720 METER VU P-47SI-B BLUE
DIODES
6602 4822 130 30621 1N4148
6603 4822 130 10791 LTL-1CHGE
6604 4822 130 10791 LTL-1CHGE
6605 4822 130 10791 LTL-1CHGE
6606 4822 130 10791 LTL-1CHGE
6610 4822 130 10791 LTL-1CHGE
6611 4822 130 10791 LTL-1CHGE
6613 4822 130 10791 LTL-1CHGE
6623 9322 153 37676 LB3333RT-E7898
6802 4822 130 10791 LTL-1CHGE
6803 4822 130 10791 LTL-1CHGE
6804 4822 130 10791 LTL-1CHGE
6840 4822 130 30621 1N4148
6841 4822 130 30621 1N4148
6842 9322 153 37676 LB3333RT-E7898
6843 4822 130 82978 LTL-1CHPE
6844 4822 130 11589 LTL-1CHAE
TRANSISTORS & INTEGRATED CIRCUITS
7602 4822 130 60511 BC847B
7800 9322 155 22667 IR Receiver TSOP2236ZC1
7841 4822 130 60511 BC847B
7842 4822 130 60373 BC857B
7843 4822 130 60511 BC847B
7844 4822 130 60511 BC847B
7845 4822 130 60373 BC857B
Note : Only the parts mentioned in this list are normal
service spare parts.
