STEP
A5
CAMERA ADDRESSING
To use FastAddress, skip to step A10.
Otherwise, to manually set the switch address,
flip the dome into the star shaped foam so the
bubble side is down.
STEP
A6
Remove the 4 top screws as shown and lift the
top plate carefully off the dome. The cable is
approximately 5 cm (2 in) long, so remove
carefully from the PCB.
Remove the top plate cable (if necessary) from
the dome to access the address switch. Set
the address switch (as in Step A7) and make a
note of it.
9
Installation Guide
Pendant/EnviroDome
