STEP
A7
If you are using RS-232 Communications:
The unit is shipped with the RS-232 Baud Rate
set to 9600.With the connector plate
removed, the baud rate can be changed with
the dip switch.
Switch 1: RS-232 Baud rate: Off = 9600,
On = 19.2K
STEP
A8
Reconnect the top plate cable. Replace the top
plate and gasket. Align the yellow dot on the
connector top with the dimple on the housing
and firmly tighten the four screws. Do not
overtighten.
11
Installation Guide
Pendant/EnviroDome
