STEP
B5
STEP
B6
While grasping the unit by the dome window,
insert the camera module, making sure that the
unit is vertical.
With the red dot on the camera module facing the
red dot on the backbox, slide the camera module
into the backbox module using the guides. Note that
the camera is shown turned 180 degrees to illus-
trate red markers.
25
Installation Guide
In-ceiling AutoDome
