STEP
B7
STEP
B8
An optional tamper clip is provided to prevent the
dome from being removed.To install, locate blue
label, orient the tamper clip with the 2 tabs pointing
up, and press the tamper clip into the locking ring
just to the right of either blue label. A straight blade
screwdriver will help push the clip in place.
While pressing up, twist the dome window/locking
ring clockwise approximately 1/4 turn.Verify that the
arrowheads on the green labels have mated.The
camera will initialize 10 seconds after it is properly
installed.
27
Installation Guide
In-ceiling AutoDome
