INSTALLATION
ATTENTION: Installation should be per-
formed by qualified service personnel only
in accordance with the National Electrical
Code or applicable local codes.
The G3 AutoDome
®
system is suitable for use in
environmental air spaces or in an air handling
plenum of a nonfire-resistant ceiling.
CAUTION: Do not remove camera from
pan/tilt. Remove the entire receiver/driver,
pan/tilt, and camera assembly from the
AutoDome system to prevent damage to
the flexible cable and connector.
To install the trim ring, align the yellow dots on the
inside of the trim ring with the yellow dots on the
locking ring.To ensure proper installation, push on
the trim ring vertically until a click is felt. Installation
is now complete.
If you are using the FastAddress feature, go to
Page 31 for additional information.
