Philips HTS3300 - Specifications; Technical Details

English
41
3139 115 2xxx1
AMPLIFIER SECTION
Output power 300 W RMS
- Front 40 W RMS / channel
- Rear 40 W RMS / channel
- Centre 70 W RMS
- Subwoofer 70 W RMS
Frequency Response 20 Hz – 20 kHz / –3 dB
Signal-to-Noise Ratio > 65 dB (CCIR)
Input Sensitivity
- AUX In 1000 mV
TUNER SECTION
Tuning Range FM 87.5 – 108 MHz (50 kHz)
MW 531 – 1602 kHz (9 kHz)
26 dB Quieting Sensitivity FM 20 dB
MW 4 µV/m
Image Rejection Radio FM 25 dB
MW 28 dB
IF Rejection Ratio FM 60 dB
MW 45 dB
Signal-to-Noise Ratio FM 60 dB
MW 40 dB
AM Suppression Ratio FM 30 dB
Harmonic Distortion FM Mono 3%
FM Stereo 3%
MW 5%
Frequency Response FM 180 Hz – 10 kHz / ±6 dB
Stereo Separation FM 26 dB (1 kHz)
Stereo Threshold FM 23.5 dB
DISC SECTION
Laser Type Semiconductor
Disc Diametre 12cm / 8cm
Video Decoding MPEG-1 / MPEG-2 / MPEG-4
/ DivX 3.11, 4.x & 5.x
Video DAC 12 Bit
Signal System PAL / NTSC
Video Format 4:3 / 16:9
Video S/N 74 dB
Composite Video Output 1.0 Vp-p, 75 Ω
Audio DAC 24 Bits / 96 kHz
Frequency Response 4 Hz – 20 kHz (44.1 kHz)
4 Hz – 22 kHz (48 kHz)
4 Hz – 44 kHz (96 kHz)
Specifications
MAIN UNIT
Power Supply Rating 220 – 240 V; 50 Hz
Power Consumption 70 W
Eco Standby power < 0.5 W
Dimensions (w x h x d) 360 mm x 54 mm x 324 mm
Weight 2.7 kg
FRONT AND REAR SPEAKERS
System 2-way, closed box system
Impedance 12 Ω
Speaker drivers 1 x 76mm (3”) woofer
Frequency response 120 Hz – 20 kHz
Dimensions (w x h x d) 94 mm x 175 mm x 65 mm
Weight 0.40 kg/each
CENTRE SPEAKER
System 2-way, closed box system
Impedance 6 Ω
Speaker drivers 1 x 76mm (3”) woofer
Frequency response 120 Hz – 20 kHz
Dimensions (w x h x d) 225 mm x 94 mm x 75 mm
Weight 0.68 kg
SUBWOOFER
Impedance 6 Ω
Speaker drivers 152 mm (6”) woofer
Frequency response 30 Hz – 120 Hz
Dimensions (w x h x d) 360 mm x 340 mm x 130 mm
Weight 3.92 kg
Specifications subject to change without prior
notice
001-045-hts3300-01-Eng1 20/1/05, 9:09 AM41
