SPECIFICATIONS
AMPLIFIER SECTION
Total output power
- Home Theater Mode ................................................700W
- FTC ..........................................................................330W
- Front & Rear ......................................................50W x2
- Center ....................................................................50W
- Subwoofer .............................................................80 W
Frequency Response .................. 180 Hz - 16 kHz / ±3 dB
Signal-to-Noise Ratio............................ > 60 dB (A-weight)
Input Sensitivity
AUX/TV In ...............................................................500 mV
TUNER SECTION
Tuning Range ................................... FM 87.5 – 108 MHz
....................................AM 530 – 1710 kHz (10 kHz steps)
26 dB Quieting Sensitivity ................................. FM 22 dBf
26 dB Quieting Sensitivity .......................... AM 5000 µV/m
Image Rejection Radio ....................................... FM 25 dB
............................................................................ AM 28 dB
IF Rejection Ratio ............................................... FM 60 dB
............................................................................ AM 24 dB
Signal-to-Noise Ratio.......................................... FM 55 dB
............................................................................ AM 40 dB
AM Suppression Ratio........................................ FM 30 dB
Harmonic Distortion ......................................FM Mono 3 %
.................................................................... FM Stereo 3 %
............................................................................... AM 5 %
Frequency Response ............ FM180 Hz – 10 kHz / ±6 dB
Stereo Separation...................................FM 26 dB (1 kHz)
Stereo Threshold ............................................. FM 23.5 dB
DISC SECTION
Laser Type .................................................. Semiconductor
Disc Diameter .................................................. 12cm / 8cm
Video Decoding ................................... MPEG-2 / MPEG-1
Video DAC ............................................................... 10 Bits
Signal System .................................................. PAL / NTSC
Video Format ....................................................... 4:3 / 16:9
Video S/N................................................ 56 dB (minimum)
Composite Video Output ............................ 1.0 Vp-p, 75 Ω
S-Video Output ...................................... Y - 1.0 Vp-p, 75 Ω
.......................................................... C - 0.286 Vp-p, 75 Ω
Audio DAC .................................................24 Bits / 96 kHz
Frequency Response .................. 4 Hz - 20 kHz (44.1kHz)
........................................................ 4 Hz - 22 kHz (48kHz)
....................................................... 4 Hz - 44 KHz (96KHz)
Digital Output ......................................................................
................... SPDIF (Sony Philips digital interface) Coaxial
- PCM ................................................................. IEC 60958
- Dolby Digital .................................IEC 60958, IEC 61937
1-3
MAIN UNIT
Power Supply Rating .................................... 120 V / 60 Hz
Power Consumption .................................................. 160W
Dimensions (w × h × d)...................... 435× 53 × 365 (mm)
Weight .................................................................... 4.25 kg
SPEAKERS
Front/Rear speakers
System ...................................................................... 2-way
Impedance .................................................................... 3 Ω
Speaker drivers ........................... 3" full-range woofer, 1"
conical dome tweeter
Frequency response ................................ 140 Hz – 20 kHz
Dimensions (w × h × d)....................... 93 × 169 × 65 (mm)
Weight ........................................... 0.73 kg (Front speaker)
0.77 kg (Rear speaker)
CENTER SPEAKERS
System ................................ 2-way, maganetically sheided
Impedance .................................................................... 3 Ω
speaker drivers ............................ 2 x 3" full-range woofer,
1" conical dome tweeter
Frequency response ................................ 140 Hz – 20 kHz
Dimensions (w × h × d)....................... 245 × 93 × 70 (mm)
Weight ..................................................................... 1.37 kg
PASSIVE SUBWOOFER
Impedance .................................................................... 3 Ω
speaker drivers ............................................. 6 1/2" woofer
Frequency response ................................ 40 Hz – 2kHz
Dimensions (w × h × d)................... 156 × 360 × 350 (mm)
Weight ....................................................................... 4.3 kg
1 1
1
2
1 3 ohm, 140 Hz - 20 kHz, 1% THD
2 3 ohm,
40 Hz - 2 kHz, 1% THD
