Philips HTS3400 - Page 36

MECHANICAL PARTS - MAIN UNIT (KN010XXXXXXXXX = BOM 2)
10-3 10-3
SUBWOOFER ASSEMBLY BREAKDOWN
ANT001 9965 000 24668 RF JACK MALE TYPE 75 OHM
L001 9965 000 23587 MOULDED COIL 2.5T 57-89NH
L02 9965 000 23586 SPRING COIL 0.8X4.5DX(1-2)2.5T
T001 9965 000 24672 AM IFT 450KHZ 180PF Q=80MIN
T002 9965 000 24673 AM IFT 450KHZ 180PF Q=80MIN
T003 9965 000 24673 AM IFT 450KHZ 180PF Q=80MIN
T005 9965 000 24674 OSC COIL AM 120UH (796KHZ)
T006 9965 000 26964 ANT OSC AM 4-6:10T 1-3:86T
VC001 9965 000 24676 CONDTRIM 3-10PF NP0
VC002 9965 000 24676 CONDTRIM 3-10PF NP0
VD001 9965 000 27006 DIODE TUNG FM 1SV101
VD002 9965 000 27006 DIODE TUNG FM 1SV101
VD003 9965 000 26965 DIODE TUNG AM 1SV149B
VD004 9965 000 26965 DIODE TUNG AM 1SV149B
VR001 9965 000 27005 CNTL TRIMR 30K OHM
XL1 9965 000 23588 CRYSTAL 75KHZ +/-15
CAPCITORS
CN002 9965 000 25150 CONNECTOR S2B-XH-A 2 PIN
CO47 9965 000 27096 COND DISC 100PF 50V 5% NPO
DIODES
D001 9965 000 26949 DIODE SW 1N4148 PB<1000PPM
D002 9965 000 26949 DIODE SW 1N4148 PB<1000PPM
D003 9965 000 26949 DIODE SW 1N4148 PB<1000PPM
D004 9965 000 26940 DIODE ZENR 11.9-12.4V 0.5W
D005 9965 000 26949 DIODE SW 1N4148 PB<1000PPM
9965 000 27195 FRAME A’SSY
9965 000 27196 CLOTH FRAME
9965 000 27197 CLOTH
9965 000 27198 PLASTIC FOOT
9965 000 26668 RUBBER FOOT
9965 000 29297 CABLE A’SSY PURPLE
MISCELLANEOUS
9965 000 27152 VOLUMR LENS PMMA LF
9965 000 23647 DVD DOOR HIPS
9965 000 27153 DISPLAY LENS PMMA L389.1XW28.7
9965 000 27149 FRONT PANEL HIPS 94V2 PAINT S
9965 000 23639 VOLUME KNOB ABS
9965 000 23650 POWER LED LENS PMMA
9965 000 29291 DVD LOADER ME L2HR3402
9965 000 27150 POWER BUTTON PAINT BLACK 8019
9965 000 23641 VOLUME RING ABS
9965 000 12817 BUSHING /21/21R/30S/37S
9965 000 23640 VOLUME DOCKING ABS
9965 000 23644 FUNCTION BUTTON 1 ABS
9965 000 27143 SAT SPK ASS’Y 100WX5 3OHM
9965 000 23571 FOOT RUBBER DIA14XT3MM WHITE
9965 000 27144 SUBWOOFER ASS’Y 100W 3OHM
9965 000 27151 OPEN/CLOSE BUTTON PAINT BALCK
9965 000 26968 DC FAN 12V 0.09A SPEED: 4000RPM
9965 000 23645 FUNCTION BUTTON 2 ABS
9965 000 27819 POWER PCB
9965 000 27816 RADIO PCB
SATELLITE SPEAKER ASSEMBLY BREAKDOWN
9965 000 27122 SPEAKER BOX-L
9965 000 27183 SPEAKER BOX-R
9965 000 27184 SPEAKER BOX SURROUND-L
9965 000 27185 SPEAKER BOX SURROUND-R
9965 000 27186 FRAME A’SSY
9965 000 27187 FRAME
9965 000 27188 CLOTH
9965 000 27189 TW BRACKET
9965 000 26663 RUBBER FOOT
9965 000 27190 SPEAKER BOX
9965 000 27191 FRAME A’SSY
9965 000 27192 FRAME
9965 000 27193 CLOTH
9965 000 27194 TW BRACKET
9965 000 24036 BRACKET & SCREW PACKING
9965 000 28778 CABLE ASS’Y L5.2M-WHITE
9965 000 28784 CABLE ASS’Y L5.2M-RED
9965 000 28786 CABLE ASS’Y L15.2M-BLUE
9965 000 28787 CABLE ASS’Y L15.2M-GRAY
ELECTRICAL PARTS LIST - CONTROL PCBA ELECTRICAL PARTS LIST - RADIO PCB ASSY (TUNER)
MISCELLANEOUS
LD2201 9965 000 26953 LED 3 DIA RED ROUND HP
SN2201 9965 000 26956 IRT RECEIVER IRM-2638F4
TA2201 9965 000 26950 AI TACT SW SKHVBE3520 ALPS
TA2202 9965 000 26950 AI TACT SW SKHVBE3520 ALPS
TA2203 9965 000 26950 AI TACT SW SKHVBE3520 ALPS
TA2204 9965 000 26950 AI TACT SW SKHVBE3520 ALPS
TA2205 9965 000 26950 AI TACT SW SKHVBE3520 ALPS
TA2206 9965 000 26950 AI TACT SW SKHVBE3520 ALPS
TA2207 9965 000 26950 AI TACT SW SKHVBE3520 ALPS
TA2208 9965 000 26952 TACT SW H5.0MM 2PIN 160GF
VR2201 9965 000 29233 ENCODER L20 A=12 WITHO CC
XL2201 9965 000 23590 CRYSTAL 4MHZ HC-49US
DIODES
D2201 9965 000 26949 DIODE SW 1N4148
D2202 9965 000 26949 DIODE SW 1N4148
DP2201 9965 000 26957 VFD 100X25MM PIN L
ZD2201 9965 000 26942 DIODE ZENR 5.0-5.2V 0.5W
ZD2202 9965 000 26930 CHIP ZENER 5.6V 0.05 0.5W
ZD2203 9965 000 26930 CHIP ZENER 5.6V 0.05 0.5W
TRANSISTOR & INTEGRATED CIRCUIT
IC2201 9965 000 23592 IC 18PIN HT48R05A-1 SOP
IC2202 9940 000 00907 IC 52 PIN TP6311QH
Q2201 9940 000 00921 XISTR PNP 2SA812 HFE:200-400
Q2202 9940 000 00921 XISTR PNP 2SA812 HFE:200-400
Q2203 9940 000 00921 XISTR PNP 2SA812 HFE:200-400
Q2204 9940 000 00915 XISTR NPN 2SC1623
Q2205 9940 000 00921 XISTR PNP 2SA812 HFE:200-400
MISCELLANEOUS
Note : Only the parts mentioned in this list are normal
service spare parts.
TRANSISTOR & INTEGRATED CIRCUIT
IC001 9965 000 27003 IC 44 PIN TEA5757H QFP44
IF001 9965 000 24093 CERFILTER 3P 10.7MHZ
IF002 9965 000 24670 CER FILTER 10.7 MHZ
Q001 4822 130 41198 2SC945P
Q002 4822 130 41198 2SC945P
Q003 9940 000 00921 XISTR PNP 2SA812 HFE:200-400
Q003 9965 000 27004 XISTR PNP BF550 SOT23
