ELECTRICAL PARTS LIST - POWER PCB
MISCELLANEOUS
F901 9965 000 29292 LF FUSE SIC 6.3A 250V SLOW
NTC901 9940 000 00957 NTC 5R 5A
L955 9965 000 26649 INDUCTOR 6UH 14.5TS 2UEW
L956 9965 000 27104 INDUCTOR 6UH /-15% D=1.0MM
L957 9965 000 27105 CHOKE 10 UH 10%
T901 9965 000 27112 SW TRANSTORMER FERRITE
T902 9940 000 01057 SW. MODEL TRANSFORMER
T903 9965 000 27113 SW TRANSTORMER FERRITE
TVR901 9940 000 00962 PTC THERMISTOR 50A 561V
TVR902 9965 000 27114 VARISTOR FOR SURGE V. TVR10
TVR903 9965 000 27114 VARISTOR FOR SURGE V. TVR10
ZD901 9965 000 27137 DIODE ZENR 17.5-18.3V 0.5W
CAPCITORS
C901 9965 000 27116 CAP.SAFTY Y1 102PF 400V 20%
C901 9965 000 27115 CAP.SAFTY Y1 102PF 250V 20%
C902 9965 000 27115 CAP.SAFTY Y1 102PF 250V 20%
C902 9965 000 27116 CAP.SAFTY Y1 102PF 400V 20%
C903 9940 000 00932 COND SAFTY 0.47UF 275V 10%
C904 9940 000 00932 COND SAFTY 0.47UF 275V 10%
C907 9965 000 27123 CAP.E 330UF 200V 20% 105’C
C908 9965 000 27123 CAP.E 330UF 200V 20% 105’C
C909 9940 000 01086 COND DISC 0.01UF 1KV 20%
C910 9940 000 01086 COND DISC 0.01UF 1KV 20%
C911 9965 000 27124 COND METAL 1.5UF 250V
C913 9940 000 01085 COND DISC 0.001UF 1KV 20%
C914 9940 000 01085 COND DISC 0.001UF 1KV 20%
C915 9965 000 27125 COND DISC 0.0022UF 1KV 20%
C916 9965 000 27126 COND DISC 100PF 1KV 10%
C917 9965 000 27127 COND MYLAR 0.1 UF 100V 5%
C923 9965 000 27129 400V 0.0022UF Y1 P=10MM 125' C
C951 9940 000 00936 COND DISC 470PF 1KV 10%
C953 9940 000 01085 COND DISC 0.001UF 1KV 20%
C954 9940 000 00936 COND DISC 470PF 1KV 10%
C955 9940 000 00936 COND DISC 470PF 1KV 10%
C956 9940 000 00936 COND DISC 470PF 1KV 10%
C958 9940 000 00936 COND DISC 470PF 1KV 10%
C959 9940 000 00936 COND DISC 470PF 1KV 10%
C961 9965 000 27130 COND ELECT 1000 UF 35V 20%
C962 9965 000 27130 COND ELECT 1000 UF 35V 20%
C963 9965 000 27131 COND DISC 0.1 UF 100V 80-20%
C964 9965 000 27131 COND DISC 0.1 UF 100V 80-20%
C977 9965 000 27132 COND MYLAR 0.001 UF 100V 5%
C981 9940 000 00937 COND DISC 220PF 1KV 10%
C982 9940 000 00937 COND DISC 220PF 1KV 10%
C983 9940 000 00937 COND DISC 220PF 1KV 10%
C984 9940 000 00937 COND DISC 220PF 1KV 10%
C985 9965 000 23606 COND ELECT 1000UF 16V 20%
C986 9965 000 27131 COND DISC 0.1 UF 100V 80-20%
C992 9965 000 27127 COND MYLAR 0.1 UF 100V 5%
C993 9965 000 29293 COND ELECT 220 UF 16 V 20%
C994 9965 000 27131 COND DISC 0.1 UF 100V 80-20%
C995 9940 000 00937 COND DISC 220PF 1KV 10%
CN901 9965 000 27100 CONNECTOR 4 PIN P=3.96MM
DIODES
D903 9965 000 26949 DIODE SW 1N4148 PB<1000PPM
D904 9965 000 26949 DIODE SW 1N4148 PB<1000PPM
D907 9940 000 00938 DIODE PR1507 1.5A 1000V
D910 9940 000 00941 DIODE HER104 1A 300V 50NS
D951 9965 000 27135 RECTIFIER FEP16DT TO-220AB
D952 9940 000 00948 RECTIFIER FEP16AT TO-220AB
D954 9965 000 26949 DIODE SW 1N4148 PB<1000PPM
D955 9965 000 26949 DIODE SW 1N4148 PB<1000PPM
D956 9965 000 26949 DIODE SW 1N4148 PB<1000PPM
D957 9965 000 26949 DIODE SW 1N4148 PB<1000PPM
D958 9965 000 26949 DIODE SW 1N4148 PB<1000PPM
D959 9940 000 00941 DIODE HER104 1A 300V 50NS
D960 9965 000 27136 DIODE IN5822 3A/45V PROCESS
D961 9965 000 26949 DIODE SW 1N4148 PB<1000PPM
ZD902 9965 000 27137 DIODE ZENR 17.5-18.3V 0.5W
ZD905 9965 000 29294 COND DISC 0.22 UF 50V 80-20%
ZD952 9965 000 27138 DIODE ZENR 3.8-4.0V 0.5W
ZD953 9965 000 27139 DIODE ZENR 23.6-24.7V 0.5W
TRANSISTOR & INTEGRATED CIRCUIT
IC901 9940 000 00946 OPTICAL SENSOR 4P
IC902 9965 000 29296 IC 8P FSDM0365RN DIP
IC951 9940 000 00949 IC 8PIN JRC4558D
IC952 9940 000 00951 IC 16PIN KA7500C
IC953 9940 000 00952 IC 3PIN TL431
Q901 9965 000 29295 STP9NK50Z TO220 ST N-CH LF
Q901 9965 000 27140 MOSFET STP9NK60Z TO-220 N-
Q902 9965 000 29295 STP9NK50Z TO220 ST N-CH LF
Q902 9965 000 27140 MOSFET STP9NK60Z TO-220 N-
Q951 9965 000 26946 XISTR PNP 2SB772P/Q NEC
Q952 9965 000 26946 XISTR PNP 2SB772P/Q NEC
Q953 4822 130 11336 STP16NF06FP
Q956 9965 000 26939 XISTR PNP 2SA952 NEC
Q957 4822 130 41198 2SC945P
Q958 4822 130 41198 2SC945P
Q959 4822 130 41198 2SC945P
RESISTORS
R909 9965 000 27133 RES.METAL OXIDE FILM 120OHM
R910 9965 000 27133 RES.METAL OXIDE FILM 120OHM
R978 9965 000 27085 FUSEABLE RES 1/4W 5%
R985 9965 000 27085 FUSEABLE RES 1/4W 5%
R986 9965 000 27085 FUSEABLE RES 1/4W 5%
Note : Only the parts mentioned in this list are normal
service spare parts.
10-5 10-5
