Circuit Diagrams and PWB Layouts

EN 71LC4.31E AA 7.

SSB .2: Diversity Tables B9-B20

B09 B15AB B16

B20 LVDS Conn.

B20 Pac-3

B17

B13

G_16210_066.eps

190106

Item Nr.

PDP 42" - 50"

LCD 26" - 32"

LCD 37" - 42"

PDP DVB 42" - 50"

PDP DVB SDI

PDP SDI

Decription

2A00 319801731040 CER2 0603 X7R 16V 100N COL

2A01 319803401010 CER1 0402 NP0 50V 100P COL

2A02 319803401010 CER1 0402 NP0 50V 100P COL

2A12 319803521030 CER2 0402 X7R 16V 10N COL

2A13 319803571040 CER2 0402 Y5V 16V 100N COL

2A14 319803521030 CER2 0402 X7R 16V 10N COL

3A00 319803106890 RST SM 0402 68R PM5 COL

3A01 319803106890 RST SM 0402 68R PM5 COL

3A02 319803101020 RST SM 0402 1K PM5 COL

3A07 319803101030 RST SM 0402 10K PM5 COL

3A08 319803101030 RST SM 0402 10K PM5 COL

3A10 319803101030 RST SM 0402 10K PM5 COL

3A11 319803101030 RST SM 0402 10K PM5 COL

3A13 319803101030 RST SM 0402 10K PM5 COL

3A14 319803104720 RST SM 0402 4K7 PM5 COL

3A15 319803103320 RST SM 0402 3K3 PM5 COL

3A16 319803101030 RST SM 0402 10K PM5 COL

4A03 319802190030 RST SM 0603 JUMP. 0R05 COL

4A04 319803190010 RST SM 0402 JUMP. 0R05 COL

4A05 319803190010 RST SM 0402 JUMP. 0R05 COL

4A06 319803190010 RST SM 0402 JUMP. 0R05 COL

5A00 319801890060 FXDIND 0805 100MHZ 30R COL R

7A00 935275998118 IC SM PCA9515ADP (PHSE) R

7A02 319801042310 TRA SIG SM BC847BW (COL) R

7A03 319801042310 TRA SIG SM BC847BW (COL) R

7A04 319801042310 TRA SIG SM BC847BW (COL) R

Item Nr.

EU 10pg TXT

EU 1000pg TXT

AP with TXT

AP non TXT

Description

2E04 202055200005 CER2 0603 X5R 6V3 4U7 PM10 R

202055200027 CER2 0603 X5R 6V3 4U7 PM10 R

2E05 202055200005 CER2 0603 X5R 6V3 4U7 PM10 R

2E06 202055200005 CER2 0603 X5R 6V3 4U7 PM10 R

2E15 319803571040 CER2 0402 Y5V 16V 100N COL

2E21 202055200005 CER2 0603 X5R 6V3 4U7 PM10 R

2E22 202055200005 CER2 0603 X5R 6V3 4U7 PM10 R

2E23 202055200005 CER2 0603 X5R 6V3 4U7 PM10 R

3E00 232270570569 RST SM 0402 RC31 56R PM5 R

3E01 232270570569 RST SM 0402 RC31 56R PM5 R

3E02 232270570569 RST SM 0402 RC31 56R PM5 R

3E13 319803103310 RST SM 0402 330R PM5 COL

319803190010 RST SM 0402 JUMP. 0R05 COL

3E14 319803103310 RST SM 0402 330R PM5 COL

319803190010 RST SM 0402 JUMP. 0R05 COL

3E15 319803103310 RST SM 0402 330R PM5 COL

319803190010 RST SM 0402 JUMP. 0R05 COL

3E16 319803103310 RST SM 0402 330R PM5 COL

3E17 319803103310 RST SM 0402 330R PM5 COL

3E18 319803103310 RST SM 0402 330R PM5 COL

3E32 319803101010 RST SM 0402 100R PM5 COL

3E34 319803101010 RST SM 0402 100R PM5 COL

3E46 319803101010 RST SM 0402 100R PM5 COL

319803101090 RST SM 0402 10R PM5 COL

4E10 319803101090 RST SM 0402 10R PM5 COL

4E11 319803101090 RST SM 0402 10R PM5 COL

5E02 242254945333 IND FXD 1206 EMI 100MHZ 120R R

5E03 242254945333 IND FXD 1206 EMI 100MHZ 120R R

6E01 319802052780 DIO REG SM BZX384-C2V7 COL R

6E03 319802052780 DIO REG SM BZX384-C2V7 COL R

7E02 932219956668 IC SM ADG781BCPZ (ANA0) R

7E03 319801071090 IC SM 74HC4053D (COL) R

7E04 319801070740 IC SM 74LCX14T (COL) R

935260739118 IC SM 74LVC14APW (PHSE) R

7E05 319801070740 IC SM 74LCX14T (COL) R

935260739118 IC SM 74LVC14APW (PHSE) R

Item Nr.

Non DVB

With DVB

Desciption

1G03 242202518872 CON H 32P F 0.50 SM FPC 0.3 R

2G31 202055200005 CER2 0603 X5R 6V3 4U7 PM10 R

202055200027 CER2 0603 X5R 6V3 4U7 PM10 R

2G32 319801741050 CER2 0603 Y5V 10V 1U COL

319803041090 ELCAP SM 16V 10U PM20 COL R

2G35 319803571040 CER2 0402 Y5V 16V 100N COL

2G36 202055200027 CER2 0603 X5R 6V3 4U7 PM10 R

2G37 202055200027 CER2 0603 X5R 6V3 4U7 PM10 R

2G38 202055200027 CER2 0603 X5R 6V3 4U7 PM10 R

2G39 202055200027 CER2 0603 X5R 6V3 4U7 PM10 R

2G40 202055200027 CER2 0603 X5R 6V3 4U7 PM10 R

2G41 202055200027 CER2 0603 X5R 6V3 4U7 PM10 R

2G45 319801731020 CER2 0603 X7R 50V 1N COL

319803501020 CER2 0402 X7R 50V 1N COL

2G48 319801741050 CER2 0603 Y5V 10V 1U COL

2G49 319801741050 CER2 0603 Y5V 10V 1U COL

2G50 319803041090 ELCAP SM 16V 10U PM20 COL R

2G51 319803571040 CER2 0402 Y5V 16V 100N COL

2G52 202055296703 CER1 0402 NP0 50V 180P PM5 R

2G53 202055296703 CER1 0402 NP0 50V 180P PM5 R

2G62 202055200035 CER2 0603 X5R 6V3 2U2 PM10 R

202055200183 CER2 0603 X5R 6V3 2U2 PM10 R

2G63 202055200035 CER2 0603 X5R 6V3 2U2 PM10 R

202055200183 CER2 0603 X5R 6V3 2U2 PM10 R

2G65 202055200005 CER2 0603 X5R 6V3 4U7 PM10 R

202055200027 CER2 0603 X5R 6V3 4U7 PM10 R

2G66 202055200005 CER2 0603 X5R 6V3 4U7 PM10 R

202055200027 CER2 0603 X5R 6V3 4U7 PM10 R

2G72 202055200005 CER2 0603 X5R 6V3 4U7 PM10 R

202055200027 CER2 0603 X5R 6V3 4U7 PM10 R

3G40 319803101010 RST SM 0402 100R PM5 COL

3G41 319803101010 RST SM 0402 100R PM5 COL

3G42 319803104730 RST SM 0402 47K PM5 COL

3G43 319803104730 RST SM 0402 47K PM5 COL

3G44 319803101020 RST SM 0402 1K PM5 COL

3G45 319803104730 RST SM 0402 47K PM5 COL

3G46 319803101020 RST SM 0402 1K PM5 COL

3G47 319803104730 RST SM 0402 47K PM5 COL

3G48 319803106890 RST SM 0402 68R PM5 COL

3G49 319803101020 RST SM 0402 1K PM5 COL

3G50 319803106890 RST SM 0402 68R PM5 COL

3G51 319803101020 RST SM 0402 1K PM5 COL

3G52 319803101020 RST SM 0402 1K PM5 COL

3G53 319803104730 RST SM 0402 47K PM5 COL

3G54 319803101020 RST SM 0402 1K PM5 COL

3G55 319803104730 RST SM 0402 47K PM5 COL

3G56 319803101010 RST SM 0402 100R PM5 COL

3G60 319803104720 RST SM 0402 4K7 PM5 COL

3G61 319803104730 RST SM 0402 47K PM5 COL

3G62 319803104730 RST SM 0402 47K PM5 COL

3G63 319803101010 RST SM 0402 100R PM5 COL

3G64 319803101010 RST SM 0402 100R PM5 COL

3G65 319803104730 RST SM 0402 47K PM5 COL

3G66 319803104730 RST SM 0402 47K PM5 COL

3G67 319803104730 RST SM 0402 47K PM5 COL

3G68 319803104730 RST SM 0402 47K PM5 COL

3G69 319803104730 RST SM 0402 47K PM5 COL

3G70 319803104730 RST SM 0402 47K PM5 COL

3G71 319803101010 RST SM 0402 100R PM5 COL

3G80 319803106890 RST SM 0402 68R PM5 COL

3G81 319803101020 RST SM 0402 1K PM5 COL

3G83 319803101030 RST SM 0402 10K PM5 COL

3G84 319803101030 RST SM 0402 10K PM5 COL

3G85 319803104730 RST SM 0402 47K PM5 COL

3G86 319803104730 RST SM 0402 47K PM5 COL

3G87 319803104730 RST SM 0402 47K PM5 COL

3G88 319803101020 RST SM 0402 1K PM5 COL

3G89 319803104730 RST SM 0402 47K PM5 COL

3G90 319803101020 RST SM 0402 1K PM5 COL

3G91 319803101020 RST SM 0402 1K PM5 COL

3G92 319803102230 RST SM 0402 22K PM5 COL

Item Nr.

LCD 37" - 42

LCD 26" - 32

PDP 42" - 50

Description

1J00 242202510771 CON V 10P M 2.00 PH B

1J01 242202510655 CON V 11P M 2.00 PH B

1J02 242202510772 CON V 12P M 2.00 PH B

1J03 242202510768 CON V 3P M 2.00 PH B

1J07 242208611081 FUSE SM T 3A 125V UL R

1J08 242254945333 IND FXD 1206 EMI 100MHZ 120R R

2J18 319803401010 CER1 0402 NP0 50V 100P COL

2J19 319803401010 CER1 0402 NP0 50V 100P COL

2J22 319803401010 CER1 0402 NP0 50V 100P COL

2J23 319803401010 CER1 0402 NP0 50V 100P COL

2J31 319803401010 CER1 0402 NP0 50V 100P COL

3J03 319803106890 RST SM 0402 68R PM5 COL

3J04 319803106890 RST SM 0402 68R PM5 COL

4J01 319803190010 RST SM 0402 JUMP. 0R05 COL

5J04 242254945333 IND FXD 1206 EMI 100MHZ 120R R

Item Nr.

26in - 32in

37in - 50in

Description

1K01 242202510772 CON V 12P M 2.00 PH B

1K04 242202510655 CON V 11P M 2.00 PH B

2K15 319803401010 CER1 0402 NP0 50V 100P COL

3K08 319803106890 RST SM 0402 68R PM5 COL

4K02 319802190030 RST SM 0603 JUMP. 0R05 COL

Item Nr.

PDP LG

LCD 37" - 42

LCD 26" - 32

PDP FHP

PDP SDI

Description

1N16 242202518772 CON V 30P M 1.25 SM 1453230 R

1N17 242202518427 CON H 31P F 1.25 SM FI-WE R

2N90 319803571030 CER2 0402 Y5V 16V 10N COL

3N30 319803101030 RST SM 0402 10K PM5 COL

3N31 319803104720 RST SM 0402 4K7 PM5 COL

3N80 319803101010 RST SM 0402 100R PM5 COL

3N81 319803101010 RST SM 0402 100R PM5 COL

4N24 319803190010 RST SM 0402 JUMP. 0R05 COL

4N26 319803190010 RST SM 0402 JUMP. 0R05 COL

4N36 319803190010 RST SM 0402 JUMP. 0R05 COL

4N37 319803190010 RST SM 0402 JUMP. 0R05 COL

7N05 319801042310 TRA SIG SM BC847BW (COL) R

Item Nr.

With Pixel Plus (Pac

Non Pixel Plus

Description

1N02 242254000017

1N03 242202518779 CON V 4P M 2.00 SM PH R

1N04 242202518196 CON V 4P M 2.00 SM PH R

242202518779 CON V 4P M 2.00 SM PH R

1N05 242212802975 SWI TACT SM H=0.5 160G SKQR R

1N19 242202518734 CON V 10P M 2.00 SM PH R

2N01 319803571040 CER2 0402 Y5V 16V 100N COL

2N02 319803571040 CER2 0402 Y5V 16V 100N COL

2N03 319803571040 CER2 0402 Y5V 16V 100N COL

2N04 319803571040 CER2 0402 Y5V 16V 100N COL

2N05 319803571040 CER2 0402 Y5V 16V 100N COL

2N06 319803571040 CER2 0402 Y5V 16V 100N COL

2N07 319803571040 CER2 0402 Y5V 16V 100N COL

2N08 319803571040 CER2 0402 Y5V 16V 100N COL

2N09 319803571040 CER2 0402 Y5V 16V 100N COL

2N10 319803571040 CER2 0402 Y5V 16V 100N COL

2N11 319803571040 CER2 0402 Y5V 16V 100N COL

2N12 319803571040 CER2 0402 Y5V 16V 100N COL

2N13 319803571040 CER2 0402 Y5V 16V 100N COL

2N14 319803571040 CER2 0402 Y5V 16V 100N COL

2N15 319803571040 CER2 0402 Y5V 16V 100N COL

2N16 319803571040 CER2 0402 Y5V 16V 100N COL

2N17 319803024790 ELCAP SM 6V3 47U PM20 COL R

2N19 319803571040 CER2 0402 Y5V 16V 100N COL

2N20 319803571040 CER2 0402 Y5V 16V 100N COL

2N21 319803571040 CER2 0402 Y5V 16V 100N COL

2N22 319803571040 CER2 0402 Y5V 16V 100N COL

2N23 319803571040 CER2 0402 Y5V 16V 100N COL

2N24 319803024790 ELCAP SM 6V3 47U PM20 COL R

2N25 319803024790 ELCAP SM 6V3 47U PM20 COL R

2N26 319803571040 CER2 0402 Y5V 16V 100N COL

2N27 319803571040 CER2 0402 Y5V 16V 100N COL

2N28 202055200005 CER2 0603 X5R 6V3 4U7 PM10 R

202055200027 CER2 0603 X5R 6V3 4U7 PM10 R

2N29 319803571040 CER2 0402 Y5V 16V 100N COL

2N30 319803571040 CER2 0402 Y5V 16V 100N COL

2N31 319803571040 CER2 0402 Y5V 16V 100N COL

2N32 319803571040 CER2 0402 Y5V 16V 100N COL

2N33 319803571040 CER2 0402 Y5V 16V 100N COL

2N35 319803571040 CER2 0402 Y5V 16V 100N COL

2N36 319803571040 CER2 0402 Y5V 16V 100N COL

2N37 319803571040 CER2 0402 Y5V 16V 100N COL

2N38 319803571040 CER2 0402 Y5V 16V 100N COL

2N39 319803571040 CER2 0402 Y5V 16V 100N COL

2N40 319803571040 CER2 0402 Y5V 16V 100N COL

2N41 319803571040 CER2 0402 Y5V 16V 100N COL

2N42 319803571040 CER2 0402 Y5V 16V 100N COL

2N43 319803571040 CER2 0402 Y5V 16V 100N COL

2N44 319803571040 CER2 0402 Y5V 16V 100N COL

2N45 319803571040 CER2 0402 Y5V 16V 100N COL

2N46 319803571040 CER2 0402 Y5V 16V 100N COL

2N47 319803571040 CER2 0402 Y5V 16V 100N COL

2N48 319803571040 CER2 0402 Y5V 16V 100N COL

2N49 319803571040 CER2 0402 Y5V 16V 100N COL

2N50 319803571040 CER2 0402 Y5V 16V 100N COL

2N51 319803024790 ELCAP SM 6V3 47U PM20 COL R

2N54 319803074780 ELCAP SM 35V 4U7 PM20 COL R
