Philips LC7.1E LA User Manual

Spare Parts List
EN 88 LC7.1E LA10.
10. Spare Parts List
Set Level per Model Number (CTN)
32PFL5322/10
0815 3139 127 09075 Main Software
0816 3139 127 09093 Main NVM Software
0821 3139 127 09103 HDMI-1 Software
0822 3139 127 09113 HDMI-2 Software
1004
h 9322 230 03682 LC320W01-SL06
1005
h 3139 128 78521 Power Supply Unit
1112 3139 268 05931 IR/LED Assy [J]
1114 3139 268 05921 Keyboard Assy [E]
1116 3139 268 08851 Side IO Assy [D]
8002 3104 311 07121 Cable 2p3/220/Inlet
8304 3104 311 08031 Cable 11p/480/11p
8520 3104 311 10701 Cable 12p/680/12p
8521 3104 311 12431 Cable 14p/180/14p
8735 3139 131 08671 Cable 4p/480 1000/2ft
8C01 3139 131 08541 Cable 9p/220/9p Bk
8G51 3139 131 08281 Cable 30p/180/30p Fi-x
8M01 3139 131 08601 Cable 3p/80/3p Bk
8M20 3139 131 08691 Cable 7p/560/7p Bk
8P11 3139 131 08581 Cable 8p/220/8p Bk
b
5213 2422 264 00605 Loudsp. 6Ω 15W FR
5215 2422 264 00607 Loudsp. 6Ω 15W Tw
32PFL5322/12
0815 3139 127 09075 Main Software
0816 3139 127 09093 Main NVM Software
0821 3139 127 09103 HDMI-1 Software
0822 3139 127 09113 HDMI-2 Software
1004
h 9322 230 03682 LC320W01-SL06
1005
h 3139 128 78521 Power Supply Unit
1112 3139 268 05931 IR/LED Assy [J]
1114 3139 268 05921 Keyboard Assy [E]
1116 3139 268 08851 Side IO Assy [D]
8002 3104 311 07121 Cable 2p3/220/Inlet
8304 3104 311 08031 Cable 11p/480/11p
8520 3104 311 10701 Cable 12p/680/12p
8521 3104 311 12431 Cable 14p/180/14p
8735 3139 131 08671 Cable 4p/480 1000/2ft
8C01 3139 131 08541 Cable 9p/220/9p Bk
8G51 3139 131 08281 Cable 30p/180/30p Fi-x
8M01 3139 131 08601 Cable 3p/80/3p Bk
8M20 3139 131 08691 Cable 7p/560/7p Bk
8P11 3139 131 08581 Cable 8p/220/8p Bk
b
5213 2422 264 00605 Loudsp. 6Ω 15W FR
5215 2422 264 00607 Loudsp. 6Ω 15W Tw
42PFL5322/10
0815 3139 127 09075 Main Software
0816 3139 127 09093 Main NVM Software
0821 3139 127 09103 HDMI-1 Software
0822 3139 127 09113 HDMI-2 Software
1004
h 9322 246 97682 LC420WX3-SLA1
1005 3122 427 24571 Power Supply Unit
1112 3139 268 05931 IR/LED Assy [J]
1114 3139 268 05921 Keyboard Assy [E]
1116 3139 268 08961 Side IO Assy [D] 42
8002 3104 311 08071 Cable 2P3/140
8304 3104 311 07951 Cable 11p/680/11p
8520 3104 311 08191 Cable 12p/1200/12p
8521 3104 311 12481 Cable 14p/400/14p Wh
8735 3139 131 08041 Cable 4p/560 820/2ft
8C01 3139 131 08521 Cable 9p/400/9p Bk
8G51 3139 131 08291 Cable 30p/280/30p Fi-x
8M01 3139 131 08601 Cable 3p/80/3p Bk
8M20 3104 311 13091 Cable 7p/560/7p Wh
8P11 3139 131 08561 Cable 8p/400/8p Bk
b
5211 2422 264 00618 Loudsp. 6Ω 15W R
5212 2422 264 00617 Loudsp. 6Ω 15W L
42PFL5322/12
0815 3139 127 09075 Main Software
0816 3139 127 09093 Main NVM Software
0821 3139 127 09103 HDMI-1 Software
0822 3139 127 09113 HDMI-2 Software
1004
h 9322 246 97682 LC420WX3-SLA1
1005
h 3122 427 24571 Power Supply Unit
1112 3139 268 05931 IR/LED Assy [J]
1114 3139 268 05921 Keyboard Assy [E]
1116 3139 268 08961 Side IO Assy [D] 42
8002 3104 311 08071 Cable 2P3/140
8304 3104 311 07951 Cable 11p/680/11p
8735 3139 131 08041 Cable 4p/560 820/2ft
8C01 3139 131 08521 Cable 9p/400/9p Bk
8G51 3139 131 08291 Cable 30p/280/30p Fi-x
8M01 3139 131 08601 Cable 3p/80/3p Bk
8M20 3104 311 13091 Cable 7p/560/7p Wh
8P11 3139 131 08561 Cable 8p/400/8p Bk
b
5211 2422 264 00618 Loudsp. 6Ω 15W R
5212 2422 264 00617 Loudsp. 6Ω 15W L
Small Signal Board [B]
Various
1101 3139 147 19801 Tuner UV1318S/A IH -3
1102 9322 042 72682 SAW 38.9MHz K3953M
1103 2422 549 44341 SAW 38.9MHz K9656M
1104 2422 543 01386 Xtal 4MHz 20p
1201 2422 543 01133 Xtal 14.32MHz 20pF
1210 2422 549 45325 Bead 67Ω at 100MHz
1211 2422 549 45325 Bead 67Ω at 100MHz
1212 2422 549 45325 Bead 67Ω at 100MHz
1213 2422 549 45325 Bead 67Ω at 100MHz
1214 2422 549 45325 Bead 67Ω at 100MHz
1215 2422 549 45325 Bead 67Ω at 100MHz
1216 2422 549 45325 Bead 67Ω at 100MHz
1301 2422 543 01526 Xtal 10MHz 12p NX8045
1304 2422 025 10655 Connector 11p m
1314 2422 025 18749 Connector 3p m
1411 2422 543 01461 Xtal 18.432MHz 12p
1504 2422 025 20251 SCART V 21p F Bk
1506 2422 025 20251 SCART V 21p F Bk
1615 2422 026 05894 Socket CINCH
1735 2422 025 09406 Connector 4p m
1810 2422 033 00617 Socket HDMI
1811 2422 033 00617 Socket HDMI
1823 2422 543 01517 Xtal 28M322 18p NX5032
1C01 2422 025 10769 Connector 9p m
1G51 2422 025 18772 Connector 30p m
1M20 4822 267 10618 Connector 7p
1P11 4822 265 11352 Connector 8p
g
2112 2020 552 00343 22μF 10% 16V
2117 5322 126 11583 10nF 10% 50V 0603
2118 5322 126 11583 10nF 10% 50V 0603
2119 2020 552 96863 100nF 50V 0603
2120 2020 552 00343 22μF 10% 16V
2121 3198 016 31590 15pF 10% 50V 0603
2122 3198 016 31590 15pF 10% 50V 0603
2123 4822 126 14247 1.5nF 50V 0603
2125 3198 017 44740 470nF 10V 0603
2126 3198 017 42240 220nF 16V Y5V 0603
2127 4822 122 33761 22pF 5% 50V
2128 5322 126 11583 10nF 10% 50V 0603
2129 2020 552 00343 22μF 10% 16V
2130 5322 126 11583 10nF 10% 50V 0603
2131 2020 552 00343 22μF 10% 16V
2132 2020 552 00343 22μF 10% 16V
2133 5322 126 11583 10nF 10% 50V 0603
2136 3198 017 44740 470nF 10V 0603
2137 5322 126 11583 10nF 10% 50V 0603
2138 5322 126 11583 10nF 10% 50V 0603
2139 4822 126 14315 390pF 5% 50V 0603
2143 5322 126 11578 1nF 10% 50V 0603
2144 5322 126 11583 10nF 10% 50V 0603
2145 5322 126 11578 1nF 10% 50V 0603
2147 2238 786 19856 330nF 20% 160V 0603
2148 2238 586 59812 100nF 20% 50V 0603
2149 2020 552 00132 2.2μF 10% 10V
2151 3198 030 81090 10μF 20% 50V
2207 2238 586 59812 100nF 20% 50V 0603
2208 4822 124 12095 100μF 20% 16V
2209 4822 124 12095 100μF 20% 16V
2210 2238 586 59812 100nF 20% 50V 0603
2211 2020 552 00291 10μF 20% 6V3 0603
2212 2238 586 59812 100nF 20% 50V 0603
2213 2238 586 59812 100nF 20% 50V 0603
2214 2238 586 59812 100nF 20% 50V 0603
2215 2238 586 59812 100nF 20% 50V 0603
2216 2020 552 00291 10μF 20% 6V3 0603
2217 2238 586 59812 100nF 20% 50V 0603
2218 2238 586 59812 100nF 20% 50V 0603
2219 2238 586 59812 100nF 20% 50V 0603
2220 2238 586 59812 100nF 20% 50V 0603
2221 2238 586 59812 100nF 20% 50V 0603
2222 2238 586 59812 100nF 20% 50V 0603
2223 2238 586 59812 100nF 20% 50V 0603
2224 2238 586 59812 100nF 20% 50V 0603
2225 2238 586 59812 100nF 20% 50V 0603
2226 2238 586 59812 100nF 20% 50V 0603
2227 2238 586 59812 100nF 20% 50V 0603
2228 2238 586 59812 100nF 20% 50V 0603
2229 2020 552 00134 22μF 20% 6.3V 0805
2230 2020 552 00291 10μF 20% 6V3 0603
2231 2238 586 59812 100nF 20% 50V 0603
2232 2238 586 59812 100nF 20% 50V 0603
2233 2238 586 59812 100nF 20% 50V 0603
2234 2238 586 59812 100nF 20% 50V 0603
2235 2238 586 59812 100nF 20% 50V 0603
2236 2020 552 00291 10μF 20% 6V3 0603
2237 2238 586 59812 100nF 20% 50V 0603
2238 2238 586 59812 100nF 20% 50V 0603
2239 2238 586 59812 100nF 20% 50V 0603
2240 2238 586 59812 100nF 20% 50V 0603
2241 2238 586 59812 100nF 20% 50V 0603
2242 2238 586 59812 100nF 20% 50V 0603
2243 2238 586 59812 100nF 20% 50V 0603
2244 2238 586 59812 100nF 20% 50V 0603
2245 2238 586 59812 100nF 20% 50V 0603
2246 2020 552 96749 20pF 5% 50V 0603
2247 2020 552 96749 20pF 5% 50V 0603
2248 2022 552 05679 1μF 10% 16V 0805
2250 2238 586 59812 100nF 20% 50V 0603
2251 2238 586 59812 100nF 20% 50V 0603
2252 2238 586 59812 100nF 20% 50V 0603
2253 2238 586 59812 100nF 20% 50V 0603
2254 2238 586 59812 100nF 20% 50V 0603
2255 2238 586 59812 100nF 20% 50V 0603
2256 2238 586 59812 100nF 20% 50V 0603
2257 2238 586 59812 100nF 20% 50V 0603
2258 2238 586 59812 100nF 20% 50V 0603
2259 2238 586 59812 100nF 20% 50V 0603
2260 2238 586 59812 100nF 20% 50V 0603
2261 2238 586 59812 100nF 20% 50V 0603
2266 2238 586 59812 100nF 20% 50V 0603
2267 2238 586 59812 100nF 20% 50V 0603
2268 2238 586 59812 100nF 20% 50V 0603
2269 2238 586 59812 100nF 20% 50V 0603
2270 2238 586 59812 100nF 20% 50V 0603
2271 2238 586 59812 100nF 20% 50V 0603
2272 2238 586 59812 100nF 20% 50V 0603
2273 2238 586 59812 100nF 20% 50V 0603
2274 2238 586 59812 100nF 20% 50V 0603
2275 2238 586 15628 2.7nF 10% 50V 0603
2276 2238 586 15628 2.7nF 10% 50V 0603
2277 2238 586 59812 100nF 20% 50V 0603
2279 2020 552 00291 10μ
F 20% 6V3 0603
2280 2020 552 00291 10μF 20% 6V3 0603
2282 2020 552 00291 10μF 20% 6V3 0603
2284 2020 552 00291 10μF 20% 6V3 0603
2286 2020 552 00291 10μF 20% 6V3 0603
2287 2020 552 00291 10μF 20% 6V3 0603
2288 2020 552 00291 10μF 20% 6V3 0603
2289 2020 552 00291 10μF 20% 6V3 0603
2290 2020 552 00291 10μF 20% 6V3 0603
2291 2020 552 00291 10μF 20% 6V3 0603
2292 2020 552 00291 10μF 20% 6V3 0603
2293 2020 552 00291 10μF 20% 6V3 0603
2295 2238 586 59812 100nF 20% 50V 0603
2296 2238 586 59812 100nF 20% 50V 0603
2297 2020 552 00134 22μF 20% 6.3V 0805
2298 2238 586 59812 100nF 20% 50V 0603
2310 2238 586 59812 100nF 20% 50V 0603
2311 2020 552 00291 10μF 20% 6V3 0603
2312 2238 586 59812 100nF 20% 50V 0603
2313 2238 586 59812 100nF 20% 50V 0603
2314 3198 016 31590 15pF 10% 50V 0603
2315 2238 586 59812 100nF 20% 50V 0603
