Philips LC7.1E LA - Page 90

Spare Parts List
EN 90 LC7.1E LA10.
6305 9322 202 10685 DF3A6.8FUG
6306 9322 202 10685 DF3A6.8FUG
6307 9322 202 10685 DF3A6.8FUG
Keyboard & Control Panel [E]
Various
1011 2422 128 02742 Switch tact SKQNAB
1012 2422 128 02742 Switch tact SKQNAB
1013 2422 128 02742 Switch tact SKQNAB
1014 2422 128 02742 Switch tact SKQNAB
1015 2422 128 02742 Switch tact SKQNAB
1016 2422 128 02742 Switch tact SKQNAB
1M01 2422 025 10775 Connector 3p m
g
2001 3198 016 34710 470pF 10% 50V 0603
f
3010 3198 021 33910 390Ω 5% 0.062W 0603
3011 3198 021 35610 560Ω 5% 0.062W 0603
3012 3198 021 31820 1.8kΩ 5% 0.062W 0603
3013 3198 021 31510 150Ω 5% 0.062W 0603
3014 3198 021 38210 820Ω 5% 0.062W 0603
3015 3198 021 90030 Jumper 0603
3016 3198 021 90030 Jumper 0603
3017 3198 021 90030 Jumper 0603
4001 3198 021 90030 Jumper 0603
d
6011 3198 020 53980 BZX384-C2V9
6012 3198 020 53980 BZX384-C2V9
6014 3198 020 55680 BZX384-C5V6
6015 3198 020 55680 BZX384-C5V6
6016 3198 020 55680 BZX384-C5V6
6017 3198 020 55680 BZX384-C5V6
6018 3198 020 55680 BZX384-C5V6
IR & LED Panel [J]
Various
1M01 2422 025 18146 Connector 3p m Wh
1M20 2422 025 18151 Connector 7p m Wh
g
2001 2020 552 00134 22μF 20% 6.3V 0805
f
3010 3198 021 33310 330Ω 5% 0.062W 0603
3011 3198 021 36820 6.8kΩ 5% 0.062W 0603
3012 3198 021 31230 12kΩ 5% 0.062W 0603
3013 3198 021 38210 820Ω 5% 0.062W 0603
3014 3198 021 31030 10kΩ 5% 0.062W 0603
3019 3198 021 31510 150Ω 5% 0.062W 0603
3020 3198 021 31510 150Ω 5% 0.062W 0603
4001 3198 021 90030 Jumper 0603
4002 3198 021 90030 Jumper 0603
4004 3198 021 90030 Jumper 0603
4005 3198 021 90030 Jumper 0603
4010 3198 021 90030 Jumper 0603
4012 3198 021 90030 Jumper 0603
4015 3198 021 90030 Jumper 0603
4017 3198 021 90030 Jumper 0603
4019 3198 021 90030 Jumper 0603
d
6010 9322 243 77676 LED L-174A2PBC
6011 9322 244 07676 LED L-174A2IT-TNB5-19
6012 3198 020 54780 BZX384-C4V7
ce
7010 9322 243 06671 IR Receiver
7011 3198 010 42030 BC847B
7012 3198 010 42030 BC847B
Niks
Various
0050 3139 120 01971 WORDMARK NI 62X12
0121 3139 123 11761 MICROFIBER CLOTH
(15 X 15)
0179 3139 124 68181 LENS ME7
0179 3139 124 71791 Lens
0259 3139 128 78181 SMALLWARE BAG
STAND 32 ME7
0259 3139 128 78191 SCR BAG STAND 37-50
ME7
0259 3139 128 78201 SMALLWARE BAG
STAND 32ME7/V
0259 3139 128 78641 SMALLWARE BAG
STAND 26/V
0259 3139 128 78741 SCR BAG STAND 37-50
ME7 /V
0404 3111 254 30351 ADHESIVE FOAM
100X6X0.5
0410 3111 254 30371 ADHESIVE FOAM
293X6X0,5
0429 3139 123 23231 PANEL FOAM
8.0X15X45
0455 3139 123 23111 EMC FOAM -3106 -L160
0485 3139 123 22931 EMC FOAM 12.7X6.4
L:42MM
0485 3139 123 22941 EMC FOAM 12.7X12.7
L:42MM
0487 3139 123 11931 FOAM 40X20X10 MM
0570 2422 015 00193 SADDLE WIRE NY66 NT
11MM5 B
0571 2422 015 00192 SADDLE WIRE NY66 NT
17MM B
0572 2422 015 00192 SADDLE WIRE NY66 NT
17MM B
0572 2422 015 00193 SADDLE WIRE NY66 NT
11MM5 B
0575 2422 015 00193 SADDLE WIRE NY66 NT
11MM5 B
0581 2422 015 00192 SADDLE WIRE NY66 NT
17MM B
0581 2422 015 00193 SADDLE WIRE NY66 NT
11MM5 B
1085 3139 238 14161 PROD ASSY
RC2023601/01 PKD
8191 2422 070 98259 Mains cord EU 2.5A 1.8m
8191 4622 001 50945 Mainscord 1.8mtr 2p
8192 2422 070 98251 Mains cord UK 2.5A 2m
f
3002 2138 101 13228 RST CRB CFR-12 A
2R2 PM5 A
