1-10
PREPARATIONS AND CONNECTIONS
16:9
(Wide screen)
4:3 LB
(Letter Box)
4:3 PS
(Pan Scan)
– TV System
Allows you to select the color system matching the
connected TV set.
A
UT
O
– If the connected TV is multi system, select this
mode.The output format will be in accordance with the
video signal of the disc.
NTSC
– If the connected TV is NTSC system, select this mode. It
will change the video signal of a PAL disc and output in
NTSC format.
PAL
– If the connected TV is PAL system, select this mode. It
will change the video signal of a NTSC disc and output in
PAL format.
– Video Out
Video out selection enables you to choose the type of
video output suitable for your DVD system.
PR PB Y / SCAR
T
– Select PR PB Y / SCART if you have connected the
video output to your TV using SCART jack.
S-VIDEO
– Select S-VIDEO if you have connected the S-VIDEO
output to your TV using S-VIDEO jack.
Note:
–You do not need to adjust the video output setting if you
are using VIDEO jack (yellow) to connect the DVD system to
your TV.
– Screen Saver
If set to ON, when you leave the system in stop or pause
mode for more than five minutes, the screen saver will be
activated. The default setting is ON.
Setting the sound
– Digital Output
Digital output selection enables you to specify the type of
digital output suitable for your amplifier or receiver.
● Select
ALL if you have connected the digital output
(COAXIAL or OPTICAL) to a multichannel decoder
receiver.
● Select PCM 96K if the external components is capable of
processing digital signal input with sampling rates of 96 kHz.
● Select PCM 48K if the external components is incapable
of processing 96 kHz digital signal input, then convert to
standard signal with sampling rates of 48 kHz.
● Select OFF to deactivate the digital output (COAXIAL or
OPTICAL).
– Night mode
Set night mode to on to level out the volume. For
example, the disc will play at the same sound level
throughout the movie. The default setting is OFF.
Night function can also be accessed via the
remote control.
Off
Select this when you want to enjoy the surround sound
with its full dynamic range.
On
Select this to level out the volume. High volume outputs
will be softened and low volume outputs are brought
upward to audible level. This feature is only available for
movies with Dolby Digital mode.
– Center Delay
If the listening position is closer to the center speaker than
the front speakers, you can set the center delay time to
improve the surround sound effect.
Options : 5ms, 3ms, 2ms, 1ms or
OFF .
– Rear Delay
If the listening position is closer to the rear surround
speakers than the front speakers, you can set the rear delay
time to improve the surround sound effect.
Options : 15ms, 12ms, 9ms, 6ms, 3ms or
OFF,.
–Test Tone (DISC mode only)
If set to ON, the system will test the speaker settings. The
test signal is generated through the left, center, right, and
rear (surround) speakers. The default setting is OFF.
Preparations
Setting the language
– Audio
– Subtitle
– Disc Menu
● This is to select the audio language, subtitle language and
the language used on TV screen menus or DVD menus
which will always be used for every disc to be played back.
The default setting is English.
● If the language selected is not available on the disc, the
original language designated by each disc will be selected.
Setting the features
–Parental
Enables setting of playback limitation level. Some DVDs may
have a parental level assigned to the complete disc or to
certain scenes on the disc, the rating levels are from 1 to 9
and are country dependent. You can prohibit the playing of
certain discs which are not suitable for your children or to
have certain discs played with alternative scenes.
The parental default initial setting is 6 PG-R
.
1
Enter the 4-digit code. If necessary, enter the code a second
time.
2
Use 3 / 4 keys select a rating level.
22
55
3
Press OK to confirm.
Rating - NO PARENTAL
Preparations
Parental control is not activated, it will play all discs.
Rating - 1 to 9
If the player’s parental level is set below 9, only discs with a
lower or equal level will play. For example, if the player is
set to 5, only discs with ratings of 5, 4, 3, 2 and 1 will be
played. Higher rated scenes will not be played unless an
alternative which has the same rating or lower is available
on the disc. For example, consider a disc that generally is
suitable for most audiences, and it is rated at level 2 for the
most part. However, in the middle, there are also scenes
rated at 5 (not suitable for children).
NO PARENTAL – It will play all discs.
8 ADULT – Mature material; should be viewed only by
adults due to graphic sexual material, violence, or language.
7 NC-17 – No children under age 17; not recommended
viewing for children under age 17.
6 PG-R – Parental Guidance - Restricted; recommended
that parents restrict children under 17 from viewing or
allow to view only when supervised by a parent or adult
guardian.
4 PG13 – Material is unsuitable for children under age 13.
3 PG – Parental Guidance suggested.
1 G – General Audience; recommended as acceptable
for viewers of all ages.
To play a higher rated disc or scene than the level
set
Enter the 4-digit code before resetting the rating level to a
higher number (go to “Password”).
If you forget the 4-digit code
1
Press 9 four times when forgotten the password and the
system will change back to the default password.
2
Go to “Password” and enter your new code.
Notes:
– Some DVDs are not encoded with a rating though the movie
rating is printed on the disc jacket. The rating level feature does
not work for such discs.
–Password
To set a new password for the parental control or to
change the password. The password supplied as default is
1234.
– Menu Language
Select the language for on screen displa
y.
– Default
If RESET is selected, all the items in the setup menu will be
reset to default setting, except Parental Setting.
