Philips LX3700D Service Manual

SPECIFICATIONS
AMPLIFIER SECTION
Power Output
- Stereo mode (DIN)................................................2 x 50 W
- Surround mode (1 kHz)............................50 W RMS/channel
Total Harmonic Distortion...........10 % at rated power (1 kHz)
Frequency Response .........................180 Hz-14 kHz/±1 dB
Signal-to-Noise Ratio........................................> 65dB(CCIR)
Input Sensitivity...........................................................400 mV
DVD SECTION
Audio Performance :
Laser Type......................................................Semiconductor
Disc Diameter.........................................................12cm/8cm
Video Decoding.......................................................Mpeg-2
Video DAC................................................................10 Bits
Signal System....................................................PAL/NTSC
Video Format........................................................4:3 / 16:9
Video S/N.....................................................65 dB (minimum)
Composite Video Output...........................1.0Vp-p, 75 ohm
S-Vodeo Output...................................Y - 1.0Vp-p, 75 ohm
........................................................C - 0.286Vp-p, 75 ohm
Audio DAC..................................Direct Digital Amplification
Frequency Response...........................4 Hz-20 kHz (44.1kHz)
............................................................. 4 Hz-22 kHz (48 kHz)
............................................................. 4 Hz-44 kHz (96 kHz)
Digital Output.................................SPDIF Coaxial & Optical
TUNER SECTION
Tuning Range........................................... FM 87.5 -108 MHz
FM Grid....................................................50 kHz /22S/25S
............................... 50 kHz/100 kHz (Switchable) /21S/21R
......................................................................... 100 kHz /37
........................AM (MW)531-1602 kHz /21S/21R/22S/25S
..................................................AM (MW)530-1710 kHz /37
AM (MW) Grid............................................9 kHz /22S/25S
................................... 9 kHz/10 kHz (Switchable) /21S/21R
........................................................................... 10 kHz /37
26 dB Quieting Sensitivity......................................FM 20 dB
26 dB Quieting Sensitivity.....................AM (MW)5000 uV/m
Image Rejection Ratio...........................................FM 25 dB
.....................................................................AM (MW) 28 dB
IF Rejection Ratio..................................................FM 60 dB
.....................................................................AM (MW) 24 dB
Signal-to-Noise Ratio..............................................FM 55 dB
.....................................................................AM (MW) 35 dB
AM Suppression Ratio...........................................FM 30 dB
Harmonic Distortion...........................................FM Mono 3%
..........................................................................FM Stereo 3%
..........................................................................AM (MW) 5%
Frequency Response.....................FM 180 Hz-10kHz/±6 dB
Stereo Separation.........................................FM 26 dB(1 kHz)
Stereo threshold..................................................FM 23.5 dB
1-3
MISCELLANEOUS / GENERAL SECTION
Power Supply Rating................110-127V/220-240V, 50/60Hz
/21R/21S
.................220-240V/50Hz /22S/25S
........................110-127V/60Hz /37
Power Consumption.................................................. 160 W
Dimensions (w x h x d)............... 390 mm x 55 mm x 399mm
Weight...........................................................................3.6 kg
IR REMOTE CZONTROL
Effective Range.........................................................> 8 Meter
Number of Keys................................................................45
Battery (1.5V)............................................................AA x 2
SPEAKERS
Front Speakers
System............................................................2-way shielded
Impedance/ ohm................................................................8Ω
Speaker drivers..................................2 x 2" woofer, 1.75" tw
Dimensions (w x h x d)................... 88 mm x 293 mm x 88 mm
Weight.................................................................... 0.65 Kg
Center Speaker
System............................................................2-way shielded
Impedance/ ohm................................................................8Ω
Speaker drivers..................................2 x 2" woofer, 1.75" tw
Dimensions (w x h x d)................280 mm x 79 mm x 72 mm
Weight.................................................................... 0.72 Kg
Surround Speakers
System............................................................2-way shielded
Impedance/ ohm................................................................8Ω
Speaker drivers..................................2 x 2" woofer, 1.75" tw
Dimensions (w x h x d)................72 mm x 283 mm x 376 mm
Weight.................................................................... 0.62 Kg
SUBWOOFER
Subwoofer (Not magnatically shielded design)...............6.5"
Input power......................................................50W (8Ω,DIN)
Dimensions (w x h x d)...............130 mm x 328 mm x 376 mm
Weight.......................................................................4.9 Kg
