3-2
SERVICE POSITIONS
Service position B
3-2
Dismantling of the Power Board
1) Loosen 6 screws "H" at the top of the Power Board as shown in
figure 13
Figure 13
J
Scart Jack use for LX3700/22S ,/25S
RGB Jack use for LX3700/21S ,LX3750/37S
Figure 11
Figure 12
I
Service position A
