Philips LX3700D Service Manual

5-4
ELECTRICAL PARTSLIST - CONTROL BOARD
- MISCELLANEOUS -
CN211B 9965 000 18027 CONNECTOR 8P
CN212B 9965 000 18028 CONNECTOR 5P
CN213 9965 000 18029 CONNECTOR 3P
CN217 9965 000 18030 CONNECTOR 2P
DP201 9965 000 18031 VFD 100X25MM
JK3001 9965 000 18032 D3.5 9P NICKEL
LD201 9965 000 17400 LED
RB211B 9965 000 18033 8P 140MM 2468#26 RAINBOW
RB212B 9965 000 18033 8P 140MM 2468#26 RAINBOW
RB213 9965 000 18034 CON/WIRE 3P 180MM
RB214 9965 000 18035 8P 160MM 2468#26
RB216 9965 000 18036 5P 150MM
RB217 9965 000 18037 2P 280MM
RB3001 9965 000 18038 4P 100MM
SN201 9965 000 10897 IR SENSOR RPM6938-V4
TA201 4822 276 13648 SWITCH
TA202 4822 276 13648 SWITCH
TA203 4822 276 13648 SWITCH
TA204 4822 276 13648 SWITCH
TA205 4822 276 13648 SWITCH
Note: Only these parts mentioned in the list are normal
TA206 4822 276 13648 SWITCH service parts.
TA207 4822 276 13648 SWITCH
TA208 4822 276 13648 SWITCH
TA209 4822 276 13648 SWITCH
VR201 9965 000 18039 ENCODER L15XA7
- COILS & FILTERS -
XL201 9965 000 17405 CRYSTAL 4.00000MHZ
- DIODES -
D201 4822 130 30621 1N4148
D202 4822 130 30621 1N4148
D204 4822 130 30621 1N4148
ZD201 4822 130 34233 BZX79-B5V1
ZD202 4822 130 34233 BZX79-B5V1
ZD203 4822 130 34233 BZX79-B5V1
ZD205 9965 000 17373 23.6-24.7V 0.5W
- IC & TRANSISTORS -
IC201 9965 000 17447 IC S-CPU EM78P156ELP
IC251 9965 000 12550 PT6311(PTC)
Q201 4822 130 63876 2SA733R
Q202 4822 130 63876 2SA733R
Q203 4822 130 63876 2SA733R
Q204 4822 130 41198 2SC945P
!
