Philips LX3700D Service Manual

6-4
ELECTRICAL PARTSLIST - RGB BOARD
- MISCELLANEOUS -
JK182 9965 000 18044 JACK 1PW/GND
JK183 9965 000 12607 DIN JACK, S-VIDEO OUT
JK184 9965 000 12609 RCA JACK R/G/B
RB181 9965 000 18045 CON/WIRE UL2854#30 5P
- COILS & FILTERS -
FB181 9965 000 12470 BEAD FERITE 100Ω/ at 100MH
Z
FB182 9965 000 12470 BEAD FERITE 100Ω/ at 100MH
Z
FB183 9965 000 12470 BEAD FERITE 100Ω/ at 100MH
Z
- DIODES -
ZD181 4822 130 31554 BZX79-B4V3
ZD182 4822 130 31554 BZX79-B4V3
ZD183 4822 130 31554 BZX79-B4V3
ZD184 4822 130 31554 BZX79-B4V3
ZD185 4822 130 31554 BZX79-B4V3
Note: Only these parts mentioned in the list are
normal service 
p
arts.
ELECTRICAL PARTSLIST - SCART BOARD
- MISCELLANEOUS -
CN101A 9965 000 18015 CONNECTOR 3P
CN101B 9965 000 15900 CONNECTOR 3P 
FB137 9965 000 12470 BEAD FERITE 100R/ at 100MHz
FB138 9965 000 12470 BEAD FERITE 100R/ at 100MHz
FB139 9965 000 12470 BEAD FERITE 100R/ at 100MHz
FB140 9965 000 12470 BEAD FERITE 100R/ at 100MHz
FB141 9965 000 12470 BEAD FERITE 100R/ at 100MHz
FB142 9965 000 12470 BEAD FERITE 100R/ at 100MHz
FB144 9965 000 12470 BEAD FERITE 100R/ at 100MHz
FB145 9965 000 12470 BEAD FERITE 100R/ at 100MHz
FB146 9965 000 12470 BEAD FERITE 100R/ at 100MHz
FB147 9965 000 12470 BEAD FERITE 100R/ at 100MHz
JK103 9965 000 18044 JACK 1PW/GND
JK401 9965 000 12607 DIN JACK, S-VIDEO OUT
JK2001 9965 000 18051 21P P=3.81MM
RB1002 9965 000 18052 CABLE 8P 300MM A=2.0mm
- DIODES -
ZD1101 9965 000 12554 ZENER 3.8-4.0V 0.5W
ZD1103 9965 000 12554 ZENER 3.8-4.0V 0.5W
ZD1104 9965 000 12554 ZENER 3.8-4.0V 0.5W
ZD1105 9965 000 12554 ZENER 3.8-4.0V 0.5W
ZD1106 9965 000 12554 ZENER 3.8-4.0V 0.5W
Note:  Only these parts mentioned in the list are
normal service 
p
arts.
