Philips LX3700D Service Manual

8-18
8-18
ELECTRICAL PARTSLIST - MAIN BOARD
- MISCELLANEOUS - - RESISTORS -
CN002 9965 000 15855 CONNECTOR S2B-XH-A 2P RA1006 9965 000 12486 RES ARRAY 4*33Ω 1/10W 5%
CN1003 9965 000 15856 CONNECTOR 20X2 P RA1007 9965 000 12486 RES ARRAY 4*33Ω 1/10W 5%
CN101 9965 000 18015 CONNECTOR 3P RA1008 9965 000 12486 RES ARRAY 4*33Ω 1/10W 5%
CN102 9965 000 18015 CONNECTOR 3P RA1009 9965 000 12486 RES ARRAY 4*33Ω 1/10W 5%
CN204 9965 000 17367 CONNECTOR 8P /21S/21R RA1010 9965 000 12486 RES ARRAY 4*33Ω 1/10W 5%
/22S/25S
CN204 9965 000 15895 CONNECTOR 5P /37 RA1011 9965 000 12486 RES ARRAY 4*33Ω 1/10W 5%
CN206 9965 000 15895 CONNECTOR 5P RA1012 9965 000 12486 RES ARRAY 4*33Ω 1/10W 5%
CN213 9965 000 15900 CONNECTOR 3P RA1013 9965 000 12486 RES ARRAY 4*33Ω 1/10W 5%
CN214 9965 000 17367 CONNECTOR 8P RA1016 9965 000 12487 RES ARRAY 4*10Ω 1/10W 5%
CN3001 9965 000 18016 CONNECTOR 4P RA1017 9965 000 12487 RES ARRAY 4*10Ω 1/10 W 5%
CN501 9965 000 18046 CONNECTOR 4P /22S/25S RA1018 9965 000 12488
RES ARRAY 4*4.7K
Ω
1/10W 5%
CN502 9965 000 18046 CONNECTOR 4P /22S/25S RA1020 9965 000 12488
RES ARRAY 4*4.7K
Ω
1/10W 5%
CN503 9965 000 18046 CONNECTOR 4P /22S/25S RA1021 9965 000 12486
RES ARRAY 4*33
Ω
1/10W 5%
CN904 9965 000 17359 CONNECTOR B8B-XH-A 8P VR102 4822 051 20392 3K90 5% 0,1W
CN905 9965 000 17360 CONNECTOR 4P CL3962WVO
CN906 9965 000 15900 CONNECTOR 3P - COILS & FILTERS -
CN951 9965 000 15863 CONNECTOR B5B-XH-A 5P
RB101A 9965 000 18048 CON/WIRE 3P 380mm /22S/25S XL1001 9965 000 17371 27.0000MHZ HC-49US +/-20PPM
RB101B 9965 000 18049 CON/WIRE 3P 250mm /22S/25S XL152 9965 000 15881 CRYSTAL 4.5 MHZ HC-49/U
JK001 9965 000 15852 FM ANT JACK L102 9965 000 15871 INDUCTOR 10µH 10%
L103 9965 000 15872 COIL 39 MHZ
JK301 9965 000 18017 TOSK JACK DLT1130 L104 9965 000 15871 INDUCTOR 10µHZ 10%
JK302 9965 000 18024 RCA JACK 2P
JK303 9965 000 17363 RCA JACK 1P /21S/21R L151 9965 000 15871 INDUCTOR 10µH 10%
JK304 9965 000 17364 AXIAL JACK 6P /21S/21R/37 L153 9965 000 15871 INDUCTOR 10µH 10%
JK304 9965 000 18047 AXIAL JACK 6P /22S/25S L154 9965 000 15871 INDUCTOR 10µH 10%
L301 9965 000 15871 INDUCTOR 10µH 10%
L302 9965 000 15871 INDUCTOR 10µH 10%
- CAPACITORS
-
L403 9965 000 17369
100
Ω
AT 100MHZ
TC001 9965 000 15865 COND TRIM 3 - 10PF NP0 L403 9965 000 15871 INDUCTOR 10µH 10%
TC002 9965 000 15866 COND TRIM 4.2 - 20PF N450 L404 9965 000 17369
100
Ω
AT 100MHZ
C549 9965 000 15930 COND MULTI 0.1µF 50V 20% L404 9965 000 15871 INDUCTOR 10µH 10%
C550 9965 000 15930 COND MULTI 0.1µF 50V 20% L501 9965 000 16695 30µH 15% 1KHZ 0.25V 2A
C555 9965 000 15930 COND MULTI 0.1µF 50V 20%
L502 9965 000 16695 30µH 15% 1KHZ 0.25V 2A
C556 9965 000 15930 COND MULTI 0.1µF 50V 20% L503 9965 000 16695 30µH 15% 1KHZ 0.25V 2A
C557 9965 000 15930 COND MULTI 0.1µF 50V 20% L504 9965 000 16695 30µH 15% 1KHZ 0.25V 2A
C558 9965 000 15930 COND MULTI 0.1µF 50V 20% L505 9965 000 16695 30µH 15% 1KHZ 0.25V 2A
C559 9965 000 15930 COND MULTI 0.1µF 50V 20% L506 9965 000 16695 30µH 15% 1KHZ 0.25V 2A
C560 9965 000 15930 COND MULTI 0.1µF 50V 20%
L507 9965 000 16695 30µH 15% 1KHZ 0.25V 2A
C561 9965 000 15930 COND MULTI 0.1µF 50V 20% L508 9965 000 16695 30µH 15% 1KHZ 0.25V 2A
C562 9965 000 15930 COND MULTI 0.1µF 50V 20% L509 9965 000 16695 30µH 15% 1KHZ 0.25V 2A
C563 9965 000 15930 COND MULTI 0.1µF 50V 20% L510 9965 000 16695 30µH 15% 1KHZ 0.25V 2A
C564 9965 000 15930 COND MULTI 0.1µF 50V 20% L511 9965 000 16695 30µH 15% 1KHZ 0.25V 2A
L512 9965 000 16695 30µH 15% 1KHZ 0.25V 2A
- RESISTORS - L513 9965 000 16692 20µH D0.5MM 4PIN
L514 9965 000 16692 20µH D0.5MM 4PIN
RA1001 9965 000 12486 RES ARRAY 4*33Ω 1/10W 5% L515 9965 000 16692 20µH D0.5MM 4PIN
RA1002 9965 000 12486 RES ARRAY 4*33Ω 1/10W 5% L516 9965 000 16692 20µH D0.5MM 4PIN
RA1003 9965 000 12486 RES ARRAY 4*33Ω 1/10W 5%
RA1004 9965 000 12486 RES ARRAY 4*33Ω 1/10W 5% L517 9965 000 16692 20µH D0.5MM 4PIN
RA1005 9965 000 12486 RES ARRAY 4*33Ω 1/10W 5% L518 9965 000 16692 20µH D0.5MM 4PIN
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!

ELECTRICAL PARTSLIST - MAIN BOARD
- COILS & FILTERS -- DIODES -
L1003 9965 000 15871 INDUCTOR 10 µH 10% ZD302 4822 130 34167 BZX79-B6V2
L1004 9965 000 15871 INDUCTOR 10 µH 10% ZD303 9965 000 14658 ZENER 8.5-8.9V 0.5W
L1005 9965 000 18025 2.4 µH 5% ZD304 9965 000 17375 11.9-12.4V 0.5W
L1006 9965 000 18025 2.4 µH 5% ZD305 9965 000 14658 ZENER 8.5-8.9V 0.5W
L1007 9965 000 18025 2.4 µH 5% ZD306 4822 130 34167 BZX79-B6V2
L1008 9965 000 18025 2.4 µH 5% ZD1002 4822 130 34167 BZX79-B6V2 /21S/21R/22S/25S
L1009 9965 000 15871 INDUCTOR 10 µH 10% ZD1003 4822 130 80272 MTZJ7.5C
L1010 9965 000 15871 INDUCTOR 10 µH 10% ZD1004 4822 130 80272 MTZJ7.5C
L9031 9965 000 15871 INDUCTOR 10 µH 10% ZD1005 4822 130 80272 MTZJ7.5C
L9032 9965 000 15871 INDUCTOR 10 µH 10% ZD1006 4822 130 80272 MTZJ7.5C
T001 9965 000 15880 OSC COIL /21S/21R/22S/25S ZD1007 4822 130 80272 MTZJ7.5C
T002 9965 000 15874 ANT OSC AM 4-6:10T 1-3:86T ZD1008 4822 130 80272 MTZJ7.5C
T003 9965 000 17370 108µH (796 KHz) COIL ZD1009 4822 130 80272 MTZJ7.5C
T101 9965 000 15877 BIAS COIL 78 KHz ZD1010 4822 130 80272 MTZJ7.5C
T102 9965 000 15875 AM IFT 455KHz Q=130 ZD1013 9965 000 17373 23.6-24.7V 0.5W
T103 9965 000 15878 BIAS COIL 16 KHz ZD1014 9965 000 17374 2.9-3.1V 0.5W
T104 9965 000 15878 BIAS COIL 16 KHz ZD3001 4822 130 80272 DIODE ZENR 6.9-7.2V 0.5W /37
T105 9965 000 15879 FM IFT 10.7MHz Q=60 MIN ZD3002 4822 130 80272 DIODE ZENR 6.9-7.2V 0.5W /37
FB1001 9965 000 17369
100
Ω
at 100MHz
VD001 4822 130 81673 1SV149
FB1002 9965 000 17369
100
Ω
at 100MHz
VD002 4822 130 81673 1SV149
FB1004 9965 000 12470
BEAD FERITE 100
Ω
/ at 100MHz
FB9001 9965 000 12470 BEAD FERITE 100
Ω
/ at 100MHz - IC & TRANSISTORS -
FB9002 9965 000 12470
BEAD FERITE 100
Ω
/ at 100MHz
FB9003 9965 000 12470
BEAD FERITE 100
Ω
/ at 100MHz
IC101 9965 000 01369 LA1837 FM/AM IF/MPX IC
CF101 9965 000 15867 CER FILTER 10.7 MHz IC151 9965 000 17382 LC72720NM /21S/21R/22S/25S
IC152 4822 209 15778 LC72131M
CF102 9965 000 15868 CER FILTER 10.7 MHz IC301 9965 000 17384 IC TP5228
CF103 9965 000 15869 CER FILTER 450 KHz IC301A 9965 000 15886 IC RC4558D
IC302 9965 000 17385 IC PT2259
- DIODES - IC304 9965 000 15886 IC RC4558D
IC305 9965 000 15886 IC RC4558D
D001 4822 130 30621 1N4148 IC306 9965 000 15886 IC RC4558D
D002 4822 130 30621 1N4148 IC307 9965 000 15886 IC RC4558D
D003 4822 130 30621 1N4148
D004 4822 130 30621 1N4148 IC308 9965 000 15886 IC RC4558D
D101 4822 130 30621 1N4148 IC401 9965 000 17383 IC STA308
IC501 9965 000 14154 STA505 50W X2
D301 4822 130 30621 1N4148 IC502 9965 000 14154 STA505 50W X2
D302 4822 130 30621 1N4148 IC503 9965 000 14154 STA505 50W X2
D303 4822 130 30621 1N4148
D304 4822 130 30621 1N4148 IC902 9965 000 12493 BA033T REGULATOR 3.3V 1A
D305 4822 130 30621 1N4148 IC1001 9965 000 12489 EEPROM AM29F080B-90EC
IC1003 9965 000 18026 IC 208P ES6028FW
D306 4822 130 30621 1N4148 IC1003 9965 000 18053 IC 208P ES6028 /37
D402 4822 130 30621 1N4148 IC1004 9965 000 15883 IC TC74HC04AFN
D1003 4822 130 30621 1N4148
D1004 4822 130 30621 1N4148 IC1005 9965 000 12494 74HC374
D3001 4822 130 30621 1N4148 /37 IC1006 9965 000 12494 74HC374
IC1007 9965 000 15884 IC AT24C02N-10SI-2.7
D3002 4822 130 30621 1N4148 /37 IC1008 9965 000 12499 SYNCHRO. DRAM 4MX16 Y3V
D3003 4822 130 30621 1N4148 IC1009 9965 000 15885 IC WM8746 6CH D/A
D9001 4822 130 31438 1N4001G
D9002 4822 130 31438 1N4001G IC1010 9965 000 12494 74HC374
ZD301 4822 130 34167 BZX79-B6V2 IC1011 9965 000 17379 IC SN74HCT244DW
