Philips LX3700D Service Manual

9-4
9-4
ELECTRICAL PARTSLIST - POWER BOARD
- MISCELLANEOUS - - DIODES -
CN902 9965 000 15936 CONNECTOR 4P P=3.96MM D905 9965 000 14186 MUR1620CT 8A 200V
CN903 9965 000 17458 CONNECTOR 3P /21S/21R D906 5322 130 32677 1N5822
CN904 9965 000 16340 CONNECTOR 5P /21S/21R D907 9965 000 14187 HER204 2A/300V 50NS
F901 9965 000 17388 FUSE 3.15A 250V SLOW D908 9965 000 14188 HER104 1A/300V 50NS
F901 9965 000 12637 FUSE 3.15A 250V UL /37 D909 4822 130 30621 1N4148
RB904 9965 000 18040 8P 100mm /22S/25S D910 4822 130 30621 1N4148
RB904 9965 000 19195 8P 140mm /21S/21R/37 ZD901 9965 000 14209 P6KE200A
RB906 9965 000 18041 3P 100MM ZD902 9965 000 15944 DIODE ZENR 5.6-5.9V 0.5W
RL901 9965 000 16331 RELAY /22S/25S ZD903 4822 130 80272 MTZJ7.5C
RL901 9965 000 15937 RELAY /21S/21R/37
SN901 9965 000 15769 PHOTO COUPLER - IC & TRANSISTORS -
T901 9965 000 17395 1.7A L1:86TS L2:86TS
T902 9965 000 17391 PWR TRANS EI-35 /21S/21R IC903 9965 000 14189 TOP249Y 250W
T902 9965 000 18050 PWR TRANS 230V /22S/25S IC904 9965 000 17387 IC TL431
T902 9965 000 19196 PWR TRANS 120V /37 Q903 9965 000 17396 PN2222A FAIRCHILD
Q904 9965 000 17397 XISTR NPN TIP120
T903 9965 000 18343 PWR TRANS /21S/21R/37 Q910 9965 000 16497 2N7000TA 60V/0.2A,
T903 9965 000 17392 PWR TRANS /22S/25S
Q912 9965 000 16497 2N7000TA 60V/0.2A,
Q913 4822 130 41651 2SC2001L
- CAPACITORS
-
C907 9965 000 18042 COND DISC 0.01µF 1KV 20%
C905 9965 000 18043 0.0022µF 400V 20%
C906 9965 000 18043 0.0022µF 400V 20%
C909 9965 000 18043 0.0022µF 400V 20%
C963 9965 000 18043 0.0022µF 400V 20%
C964 9965 000 18043 0.0022µF 400V 20%
C968 9965 000 18043 0.0022µF 400V 20%
- RESISTORS -
R905 9965 000 17393
68K
Ω
2W 5% W/KINK
R906 9965 000 17393
68K
Ω
2W 5% W/KINK
R928 9965 000 16691
120
Ω
1/2W
R952 9965 000 12517
1
Ω
1/2W 5%
Note: Only these parts mentioned in the list are
- COILS & FILTERS -
normal service parts.
RT901 9965 000 17394
5
Ω
5A
L901 9965 000 16693 6µH 10.5TS 6A
L902 9965 000 16694 6µH 13.5TS 2UEW
L903 9965 000 16694 6µH 13.5TS 2UEW
- DIODES -
BR901 9965 000 14146 ZENER 6.4-6.7V 0.5W
D901 4822 130 11044 BYV26D
D902 4822 130 30621 1N4148
D903 4822 130 31438 1N4001G
D904 4822 130 30621 1N4148
!
!
!
!
!
!
!
!
!
!
!
!
