Preparations
Rear connections
The type plate is located at the rear of the
system.
A Power
Before connecting the AC power cord to the
wall outlet, ensure that all other connections
have been made.
WARNING!
– For optimal performance, use only the
original power cable.
– Never make or change connections with
the power switched on.
To avoid overheating of the system, a safety
circuit has been built in. Therefore, your
system may switch to Standby mode
automatically under extreme conditions. If
this happens, let the system cool down
before reusing it.
B Antennas Connection
Connect the supplied AM loop antenna and FM
antenna to the respective terminals. Adjust the
position of the antenna for optimal reception.
AM Antenna
¶ Position the antenna as far as possible from a TV,
VCR or other radiation source.
R
+
–
L
–
+
SUB
WOOFER OUT
DIGITAL
OUT
AM ANTENNA
L
R
speaker
(right)
speaker
(left)
FM wire antenna
AM loop
antenna
B
C
AC
MAINS
SPEAKERS 6Ω
AUX/CDR IN
AC power cord
A
FM ANTENNA
