Philips MC-M570/21 - ELECTRICAL PARTSLIST 5 DTC MODULE MP3 CD Version Control Board; Mechanical Parts; Miscellaneous; Capacitors

MECHANICAL PARTS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
3103 308 54710 5DTC Module (mechanic w/o electronic)
MISCELLANEOUS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
1801 2422 025 17065 FFC-CONNECTOR 16P, top entry
1802 2422 025 17788 FFC-CONNECTOR 8P, top entry
8021 3103 308 93110 FFC-CABLE 16Pin 60mm AD
CAPACITORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
2800 © 4822 126 13879 220nF 20% 16V
2801 © 2238 586 59812 100nF 10% 50V
2802 © 2238 586 59812 100nF 10% 50V
2803 © 2238 586 59812 100nF 10% 50V
2808 4822 124 40433 47µF 20% 25V
2810 © 3198 017 34730 47nF 10% 16V
2811 © 2238 586 59812 100nF 10% 50V
2812 © 2238 586 59812 100nF 10% 50V
2813 © 2238 586 59812 100nF 10% 50V
2814 © 2238 586 59812 100nF 10% 50V
RESISTORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
3800 © 4822 051 30472 4,7kΩ 5% 0,06W
3801 © 4822 051 30472 4,7kΩ 5% 0,06W
3802 © 4822 051 30472 4,7kΩ 5% 0,06W
3803 © 4822 051 30472 4,7kΩ 5% 0,06W
3804 © 4822 051 30472 4,7kΩ 5% 0,06W
3805 © 4822 051 30472 4,7kΩ 5% 0,06W
3806 © 4822 051 30472 4,7kΩ 5% 0,06W
3807 © 4822 051 30472 4,7kΩ 5% 0,06W
3808 © 4822 051 30472 4,7kΩ 5% 0,06W
3809 © 4822 051 30472 4,7kΩ 5% 0,06W
3810 © 4822 051 30103 10kΩ 5% 0,06W
3811 © 4822 051 30154 150kΩ 5% 0,0625W
3815 © 5322 117 13057 820Ω 1% 0,06W
3816 © 4822 051 30479 47Ω 5% 0,06W
3818 © 4822 051 30479 47Ω 5% 0,06W
3819 © 5322 117 13057 820Ω 1% 0,06W
3820 © 5322 117 13057 820Ω 1% 0,06W
3821 © 4822 051 30479 47Ω 5% 0,06W
3823 © 4822 051 30479 47Ω 5% 0,06W
3824 © 5322 117 13057 820Ω 1% 0,06W
3826 ! 4822 117 12148 1,5Ω 5% 0,33W
3827 © 4822 051 30101 100Ω 5% 0,06W
3828 © 4822 051 30101 100Ω 5% 0,06W
3829 © 4822 051 30101 100Ω 5% 0,06W
3830 © 4822 051 30103 10kΩ 5% 0,06W
3831 © 4822 051 30103 10kΩ 5% 0,06W
3832 © 4822 051 30272 2,7kΩ 5% 0,06W
3833 © 4822 051 30272 2,7kΩ 5% 0,06W
3834 © 4822 051 30272 2,7kΩ 5% 0,06W
3835 © 4822 051 30272 2,7kΩ 5% 0,06W
3836 © 4822 051 30272 2,7kΩ 5% 0,06W
3837 © 4822 051 30272 2,7kΩ 5% 0,06W
3838 © 4822 051 30103 10kΩ 5% 0,06W
3839 © 4822 051 30272 2,7kΩ 5% 0,06W
3840 © 4822 051 30272 2,7kΩ 5% 0,06W
3841 © 4822 051 30103 10kΩ 5% 0,06W
3842 © 4822 051 30103 10kΩ 5% 0,06W
3845 © 4822 051 20159 15Ω 5% 0,1W
3850 © 4822 117 12706 10kΩ 1% 0,06W
3851 © 4822 117 12706 10kΩ 1% 0,06W
3852 © 4822 117 12706 10kΩ 1% 0,06W
3853 © 4822 117 12706 10kΩ 1% 0,06W
3854 © 4822 117 12706 10kΩ 1% 0,06W
RESISTORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
3855 © 4822 117 12706 10kΩ 1% 0,06W
3856 © 4822 117 12706 10kΩ 1% 0,06W
3857 © 4822 117 12706 10kΩ 1% 0,06W
3858 © 4822 051 30102 1kΩ 5% 0,06W
3859 © 4822 051 30103 10kΩ 5% 0,06W
3860 © 5322 117 13017 100Ω 1% 0,06W
3861 © 2322 704 62002 2kΩ 1% 0,06W
3862 © 4822 117 12706 10kΩ 1% 0,06W
3863 4822 053 10228 2,2Ω 5% 1W
4800 © 4822 051 30008 CHIP JUMPER 0603
4802 © 4822 051 30008 CHIP JUMPER 0603
4803 © 4822 051 30008 CHIP JUMPER 0603
4804 © 4822 051 30008 CHIP JUMPER 0603
4805 © 4822 051 20008 CHIP JUMPER 0805
4806 © 4822 051 30008 CHIP JUMPER 0603
4807 © 4822 051 30008 CHIP JUMPER 0603
4808 © 4822 051 30008 CHIP JUMPER 0603
4809 © 4822 051 20008 CHIP JUMPER 0805
4810 © 4822 051 20008 CHIP JUMPER 0805
4811 © 4822 051 30008 CHIP JUMPER 0603
4812 © 4822 051 30008 CHIP JUMPER 0603
4813 © 4822 051 30008 CHIP JUMPER 0603
4814 © 4822 051 30008 CHIP JUMPER 0603
4816 © 4822 051 20008 CHIP JUMPER 0805
4817 © 4822 051 20008 CHIP JUMPER 0805
4818 © 4822 051 20008 CHIP JUMPER 0805
4819 © 4822 051 30008 CHIP JUMPER 0603
4820 © 4822 051 30008 CHIP JUMPER 0603
4821 © 4822 051 20008 CHIP JUMPER 0805
4822 © 4822 051 20008 CHIP JUMPER 0805
COILS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
1800 4822 242 72066 CERAMIC FILTER 8,0MHz
TRANSISTORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
7806 © 3198 010 42320 BC857BW
INTEGRATED CIRCUITS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
7800 4822 209 72042 MC78L05ACP, STABILIZER
7801 © 3103 307 01640 TMP87P809M Microcontroller
7803 4822 209 62059 TCA0372DP1, 2-FOLD OP-AMP.
7805 4822 209 62059 TCA0372DP1, 2-FOLD OP-AMP.
10-19
ELECTRICAL PARTSLIST 5DTC MODULE MP3CD Version Control Board
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
