Philips MC-M570/21 - ELECTRICAL PARTS LIST (MP3 Board); Miscellaneous and Capacitors; Resistors; Coils and Diodes

MISCELLANEOUS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
1451 2422 025 17303 FFC-CONNECTOR 19P,side entry
CAPACITORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
2450 © 2238 586 59812 100nF 10% 50V
2451 © 3198 017 41050 1µF 20% 10V
2452 © 3198 017 41050 1µF 20% 10V
2453 © 2238 586 59812 100nF 10% 50V
2454 © 2238 586 59812 100nF 10% 50V
2455 © 2238 586 59812 100nF 10% 50V
2456 © 2238 586 59812 100nF 10% 50V
2457 © 5322 126 11583 10nF 10% 63V
2458 © 5322 126 11583 10nF 10% 63V
2459 © 3198 017 41050 1µF 20% 10V
2460 © 2238 586 59812 100nF 10% 50V
2461 © 4822 124 81059 220µF 20% 4V
2462 © 3198 017 41050 1µF 20% 10V
2463 © 3198 017 41050 1µF 20% 10V
2464 © 2238 586 59812 100nF 10% 50V
2465 © 2238 586 59812 100nF 10% 50V
2466 © 2238 586 59812 100nF 10% 50V
2467 © 3198 017 41050 1µF 20% 10V
2468 © 3198 017 41050 1µF 20% 10V
2469 © 2238 586 59812 100nF 10% 50V
2470 © 2238 586 59812 100nF 10% 50V
2471 © 2238 586 59812 100nF 10% 50V
RESISTORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
3449 © 4822 051 30101 100Ω 5% 0,06W
3450 © 4822 117 12971 15Ω 5% 0,06W
3451 © 4822 117 12971 15Ω 5% 0,06W
3452 © 4822 051 30101 100Ω 5% 0,06W
3453 © 4822 051 30109 10Ω 5% 0,06W
3454 © 4822 117 12971 15Ω 5% 0,06W
3455 © 4822 051 30102 1kΩ 5% 0,06W
3456 © 4822 051 30102 1kΩ 5% 0,06W
3457 © 5322 117 13051 680Ω 1% 0,06W
3458 © 5322 117 13061 180Ω 1% 0,06W
3459 © 4822 051 30221 220Ω 5% 0,06W
3460 © 4822 051 30102 1kΩ 5% 0,06W
3461 © 4822 051 30479 47Ω 5% 0,06W
3462 © 4822 051 30101 100Ω 5% 0,06W
3463 © 4822 051 30101 100Ω 5% 0,06W
3464 © 4822 051 30103 10kΩ 5% 0,06W
3465 © 4822 051 30101 100Ω 5% 0,06W
3466 © 4822 051 30471 470Ω 5% 0,06W
3467 © 4822 051 30103 10kΩ 5% 0,06W
3468 © 4822 051 30103 10kΩ 5% 0,06W
3469 © 4822 051 30101 100Ω 5% 0,06W
3470 © 4822 117 12971 15Ω 5% 0,06W
3471 © 4822 051 30339 33Ω 5% 0,06W
3472 © 4822 051 30154 150kΩ 5% 0,06W
3473 © 4822 117 13632 100kΩ 1% 0,06W
3474 © 4822 117 12971 15Ω 5% 0,06W
3475 © 4822 051 30101 100Ω 5% 0,06W
3476 © 4822 051 30101 100Ω 5% 0,06W
3477 © 4822 051 30471 470Ω 5% 0,06W
3478 © 4822 051 30471 470Ω 5% 0,06W
3479 © 4822 051 30471 470Ω 5% 0,06W
3480 © 4822 051 30101 100Ω 5% 0,06W
3481 © 4822 051 30101 100Ω 5% 0,06W
3482 © 4822 051 30471 470Ω 5% 0,06W
3483 © 4822 051 30101 100Ω 5% 0,06W
RESISTORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
3484 © 4822 117 12971 15Ω 5% 0,06W
3486 © 4822 051 30101 100Ω 5% 0,06W
3488 © 4822 117 13632 100kΩ 1% 0,06W
3489 © 4822 051 30103 10kΩ 5% 0,06W
3490 © 4822 051 30101 100Ω 5% 0,06W
3491 © 4822 051 30479 47Ω 5% 0,06W
3492 © 4822 051 30105 1MΩ 5% 0,06W
3493 © 4822 051 30103 10kΩ 5% 0,06W
3494 © 4822 051 30103 10kΩ 5% 0,06W
3495 © 4822 051 30103 10kΩ 5% 0,06W
3497 © 4822 051 30103 10kΩ 5% 0,06W
3498 © 4822 051 30332 3,3kΩ 5% 0,06W
3499 © 4822 051 30103 10kΩ 5% 0,06W
4450 © 4822 051 30008 CHIP JUMPER 0603
COILS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
1460 4822 242 10989 CER.RES. 16,9MHz
5450 © 4822 157 11074 100µH
DIODES
–––––––––––––––––––––––––––––––––––––––––––––––––––––
6450 © 4822 130 11411 BZX284-C3V3
6451 © 4822 130 11366 BZX284-C3V9
7454 4822 130 34174 BZX79-B4V7
TRANSISTORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
7452 © 3198 010 42310 BC847BW
7453 © 3198 010 42310 BC847BW
7456 © 3198 010 42310 BC847BW
7460 © 3198 010 42310 BC847BW
INTEGRATED CIRCUITS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
7451 © not available please order complete MP3 Board
7455 © 4822 209 17108 LM317LD Voltage Regulator
7457 © 9352 456 50115 HC1G04, Inverter
7458 © 9322 130 41668 M24C64, EEPROM
3103 308 67020 MP3 Board
10-20
ELECTRICAL PARTSLIST 5DTC MODULE MP3CD Version MP3 Board
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
