Philips MCD109/98 - Electrical Parts List - Key & Vfd Board

5 - 4
ELECTRICAL PARTS LIST - KEY & VFD BOARD
D2000 9965 000 19409 DIODE BAV16W/IN4148W
D2001 9965 000 19409 DIODE BAV16W/IN4148W
D2002 9965 000 19409 DIODE BAV16W/IN4148W
D2003 9965 000 19409 DIODE BAV16W/IN4148W
D2004 9940 000 05475 ZENER 5.1V 5% 0.5W(E1)
D2005 9940 000 05475 ZENER 5.1V 5% 0.5W(E1)
D2500 9965 000 19409 DIODE BAV16W/IN4148W
DP200 9940 000 05469 VFD 35P AOTOM:33082-1A01
IC200 9965 000 12550 IC 52P PT6311
L2004 9940 000 05471 CHOKE 1µH 5%
LD200 9940 000 05468 LED D2.94 BLUE ROUND 2P
Q2000 9940 000 00915 XISTR NPN 2SC1623
Q2002 9940 000 00915 XISTR NPN 2SC1623
Q2500 9940 000 05335 XISTR NPN TIP41C
Q2501 9965 000 28742 XISTR NPN 2SD882P
Q2502 9940 000 00915 XISTR NPN 2SC1623
Q2503 9940 000 00915 XISTR NPN 2SC1623
SN200 9940 000 05472 IRT RECEIVER IRM-2638AF4
T2500 9940 000 05473 OSC COIL 160µH 8% 796KHz
T2501 9965 000 22303 OSC COIL REC OSC 3mH
TA200 4822 276 13648 TACT SW SKHVBE3520
TA201 4822 276 13648 TACT SW SKHVBE3520
TA202 4822 276 13648 TACT SW SKHVBE3520
TA203 4822 276 13648 TACT SW SKHVBE3520
TA204 4822 276 13648 TACT SW SKHVBE3520
TA205 4822 276 13648 TACT SW SKHVBE3520
TA206 4822 276 13648 TACT SW SKHVBE3520
TA207 4822 276 13648 TACT SW SKHVBE3520
TA208 4822 276 13648 TACT SW SKHVBE3520
TA209 4822 276 13648 TACT SW SKHVBE3520
TA210 4822 276 13648 TACT SW SKHVBE3520
TA211 4822 276 13648 TACT SW SKHVBE3520
TA212 4822 276 13648 TACT SW SKHVBE3520
TA213 4822 276 13648 TACT SW SKHVBE3520
ZD200 9940 000 05475 DIODE ZENER 5.1V 5% 0.5W
ZD201 9940 000 05476 DIODE ZENER 5.6V 0.5W 5%
ZD202 9940 000 05476 DIODE ZENER 5.6V 0.5W 5%
ZD250 9940 000 05477 DIODE ZENER 19.5-20.4V 0.5W
ZD251 9940 000 05478 DIODE ZENER 9.1V 5% 0.5W
Note: Only these parts mentioned in the list are
normal service parts.
!
Ω
5 - 4
