Philips MCD109/98 - Amplifier Board

AMPLIFIER BOARD
TABLE OF CONTENTS
Voltage ............................................................................. 7-1
Circuit Diagram ................................................................7-2
PCB Layout Top & Bottom View ......................................7-3
Electrical Parts List .......................................................... 7-4
7-1 7-1
Pin NO 12345678
Voltage 11.00 2.50 -0.1 -0.1 0.30 27.00 0.30 0.00
Pin NO 12345678
Voltage 11.00 2.50 -0.12 -0.1 1.00 27.00 0.40 0.00
Pin NO 12345678
Voltage 16.30 16.30 -0.1 -0.1 22.80 27.00 16.00 0.00
Pin NO 12345678
Voltage 16.30 16.20 -0.1 -0.1 22.00 26.70 16.00 0.00
IC500-MP9720DS
IC501-MP9720DS
IC502-MP9720DS
IC503-MP9720DS
Voltage
