12. Interrupt modes
[1] Bit 7 of Clock division factor byte of Set mode command (see Table 6).
[2] Bit 5 of Set DMA command (see Tabl e 7 ).
[3] Normal interrupts from Interrupt Register.
13. Limiting values
[1] Equivalent to discharging a 100 pF capacitor via a 1.5 kΩ resistor.
[2] Values are given for device only; in-circuit V
esd(max)
= ±8000 V.
Table 11: Interrupt modes
SOF-ONLY INTERRUPT MODE
[1]
INTERRUPT PIN MODE
[2]
Interrupt types
0 0 Normal
[3]
0 1 Normal + SOF
[3]
1 X SOF only
Table 12: Limiting values
In accordance with the Absolute Maximum Rating System (IEC 60134).
Symbol Parameter Conditions Min Max Unit
V
CC
supply voltage −0.5 +6.0 V
V
I
input voltage −0.5 V
CC
+ 0.5 V
I
latchup
latchup current V
I
< 0 or V
I
>V
CC
− 100 mA
V
esd
electrostatic discharge
voltage
I
LI
<1µA
[1][2]
−±2000 V
T
stg
storage temperature −60 +150 °C
P
tot
total power dissipation V
CC
= 5.5 V − 95 mW
Table 13: Recommended operating conditions
Symbol Parameter Conditions Min Max Unit
V
CC1
DC supply voltage
(Main mode)
apply V
CC1
to V
CC
pin only
4.0 5.5 V
V
CC2
DC supply voltage
(Alternate mode)
apply V
CC2
to both
V
CC
and V
out3.3
pins
3.0 3.6 V
V
I
DC input voltage 0 5.5 V
V
I/O
DC input voltage for I/O 0 5.5 V
V
AI/O
DC input voltage for
analog I/O
0 3.6 V
V
O
DC output voltage 0 V
CC
V
T
amb
operating ambient
temperature in free air
See Section 14
and Section 15
per device.
−40 +85 °C
