16. Test information
The dynamic characteristics of the analog I/O ports (D+ and D−) as listed in Tabl e 16 ,
were determined using the circuit shown in Figure 22.
Fig 22. Load for D+/D−.
D. U. T.
TEST POINT
C
L
= 50pF
1.5kΩ IS INTERNAL
15kΩ
22Ω
SV00849
