Screw Torque Specification
*: For reference
1. Disassembly Flowchart
This flowchart indicates the disassembly steps for the
cabinet parts and the CBA in order to gain access to
items to be serviced. When reassembling, follow the
steps in reverse order. Bend, route and dress the
cables as they were.
2. Disassembly Method
Ref.
No.
Part
Number
Part Name ID. No.
Tightening
Torque
L010 GCHP3120
SCREW F-PAN BLACK_NI +P-TITE M3X12.0 3X12
WASHER HEAD+BLK
S-3, S-6
5.2±0.9lb·inL023 GBJS3060
SCREW BIND 3CHROM +S-TITE M3X6.0 M3X6
BIND HEAD+
S-8, S-9, S-12
L028 GCHS3080
SCREW F-PAN BLACK_NI +S-TITE M3X8.0 3X8
WASHER HEAD+BLAC
S-2, S-5, S-10, S-11
L076 2EML00004 SCREW M M3X7 LOW HEAD3X7 S-13 3.5±0.4lb·in
L094 SDJ33080 SCREW M3X8 SARA+ S-14
5.2±0.9lb·in
L128 2EML00041
SCREW M3X8 WIDTH LOW HEAD BLACK
AA7R1UH
S-4, S-7
SSK1 2ESA07654
STAND SCREW KIT ACLRZUT-55UL(SCREW
BIND BLACK_NI +P-TITE M4X18.0 M4X18 BIND
HEAD+)
S-1
(approx.
8.7±0.9lb·in)
*
[9] IR Sensor
CBA Unit
[13] LCD Panel
Assembly
[12] Cell Assembly
[7] Speaker
[2] Rear Cover L
[3] Rear Cover R
[1] Stand
Assembly
[10] AC Cord
Holder
[11] T-CON Holder
[14] Front Bezel
[5] Digital Main
CBA Unit
[4] Power Supply
CBA
[6] WiFi Module
[8] Speaker
Holder
Step/
Loc.
No.
Part
Fig.
No.
Removal Note
[1]
Stand
Assembly
D1 4(S-1) ---
[2]
Rear Cover
L
D1 6(S-2), (S-3), 3(S-4) ---
[3]
Rear Cover
R
D1 6(S-5), (S-6), 3(S-7) ---
[4]
Power
Supply
CBA
D2
W1
3(S-8), CN601,
CN651, CN652,
CN1001
---
[5]
Digital Main
CBA Unit
D2
W1
5(S-9), CN3102,
CN3705, CN3801,
CN3901
---
[6]
WiFi
Module
D2 Cushion ---
[7] Speaker D3 ---------- ---
[8]
Speaker
Holder
D3 2(S-10) ---
[9]
IR Sensor
CBA Unit
D3
W1
Stand Rubber Foot,
Sensor Lens, Sensor
Shield
1
[10]
AC Cord
Holder
D3 (S-11) ---
[11]
T-CON
Holder
D4
4(S-12), FFC Cable,
T-CON Module,
Separation Sheet
(Shield), Separation
Sheet (T-CON)
3
[12]
Cell
Assembly
D5
3(S-13), Decoration
Bezel
2
To Next Page
