2021/12/14 13-1 AF1R1_CA
PARTS LIST [55PUL7472/F7 (Serial No.: ME1)]
Mechanical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
LCD PANEL ASSEMBLY
Ref.No. Description Parts No.
A003-1 REAR COVER L AF1R1UT-55UB 2EMM02152
A003-2 REAR COVER R AF1R1UT-55UB 2EMM02153
A009 SENSOR LENS AFDF0UT-32HB 2EMM02131
A015# RATING LABEL AF1R1UT-55UB ----------
A017 ENERGY GUIDE LABEL AF1R1UT-55UB ----------
A045 STAND RUBBER FOOT AC1R0UT-55UL 2EMZ01565
A105 AC CORD HOLDER AFDF0UT-32HB 2EMM02132
AC601# AC CORD W/O A GND WIRE UL/CSA/1680/NO/
BLACK
WAC162LUX001
B004 CUSHION ACLF0UT-32HS HK2EMZ01277
B012 SENSOR SHIELD AFDF0UT-32HB 2EMS00968
B014 SPEAKER HOLDER AD18GUT-65UB 2EMM02075
CL652 WIRE ASSEMBLY 2PIN 2PIN/140MM WX1AF7U0C213
CL3102 FFC WIRE ASSEMBLY 5PIN 5PIN/FFC/208MM WX1AF7U0C301
CL3601 FFC WIRE ASSEMBLY 27PIN 27PIN/FFC/
158MM
WX1AF1R1C102
CL3705 WIRE ASSEMBLY 10PIN 10PIN/
170MM_110MM
WX1AF1R1C402
CL3715 RF PCB ANT ASSEMBLY (L120MM) C1914-
510008-A
UANZZZWHA004
CL3801 WIRE ASSEMBLY 2PIN 2PIN/120MM WX1AF7U0C201
CL3901 FFC WIRE ASSEMBLY 51PIN(W/SHIELD) 51P/
FFC/SHIELD/130MM
WX1AD1U6T501
L010 SCREW F-PAN BLACK_NI +P-TITE M3X12.0
3X12 WASHER HEAD+BLK
GCHP3120
L023 SCREW BIND 3CHROM +S-TITE M3X6.0 M3X6
BIND HEAD+
GBJS3060
L028 SCREW F-PAN BLACK_NI +S-TITE M3X8.0 3X8
WASHER HEAD+BLAC
GCHS3080
L128 SCREW M3X8 WIDTH LOW HEAD BLACK
AA7R1UH
2EML00041
MB035 SERIAL NUMBER LABEL U2AN0XT ----------
SA001 STAND ASSEMBLY AF7U0UT-50UX 2ESA08970
SP652 SPEAKER MAGNETIC S0411F41 DS08110XQ013
SP3801 SPEAKER MAGNETIC S0411F41 DS08110XQ013
SSK1 STAND SCREW KIT ACLRZUT-55UL(SCREW
BIND BLACK_NI +P-TITE M4X18.0 M4X18
BIND HEAD+)
2ESA07654
WF301 WIRELESS MODULE U9W42YT U9W42YT
S001 CARTON AF1R1UT-55UB 2EMC02727
S003 STYROFOAM TOP AF1R1UT-55UB 2EMC02728
S004 STYROFOAM BOTTOM AF1R1UT-55UB 2EMC02729
S006 SET BAG AA7RSUT-55UL 2EMC01948
S007 SERIAL NO. LABEL AFDF0UT-32HB ----------
S033 CARDBOARD PLATE AF1R1UT-55UB 2EMC02730
X001 POLYETHYLENE BAG HDPE 180X340XT0.03 1EM435579
X002# SAFETY WARRANTY SHEET AF1R1UT-55UB 2EMN01201
X003 REMOTE CONTROL UNIT 135439A0001 URMT26CND001
X004 BATTERY DRY R03PVKDS2ZZD XB00M0CLB003
X006 QUICK START GUIDE (EN) AF1R1UT-55UB 2EMN01202
X028 CAUTION SHEET AF1R1UT-55UB 2EMN01200
X035 QUICK START GUIDE (FR) AF1R1UT-55UB 2EMN01203
Ref.No. Description Parts No.
LCD1# LCD PANEL ASSEMBLY UFFR0PA
Consists of the following
A001 FRONT BEZEL AF1R1UT-55UB 2EMM02151
When servicing the FRONT BEZEL, RUBBER SPACER 600X2.3X0.7
(HK2EMZ01710), DOUBLE SIDE TAPE 610X3X0.86 (2EMZ01695),
DOUBLE SIDE TAPE 689X3X0.86 (2EMZ01696), and DIFFUSING
PLATE CUSHION(T2.5) (HK2EMZ01205), needs to be ordered and
replaced together.
A055 DECORATION BEZEL AF1R1UT-55UB 2EMM02154
B007 T-CON HOLDER AC1RBUT-55UB 2EMS00895
B016 SEPARATION SHEET(T-CON) AA8V0JT-43UL 2EMH01312
B045 SEPARATION SHEET(SHIELD) AA8V0JT-43UL 2EMH01313
L023 SCREW BIND 3CHROM +S-TITE M3X6.0 M3X6
BIND HEAD+
GBJS3060
L076 SCREW M3X7 M3X7 LOW HEAD 2EML00004
L094 SCREW M3X8 SARA+ SDJ33080
MB002 RADIATION PLATE AF1R1UT-55UB 2EMS00978
MB016 RUBBER SPACER 600X2.3X0.7 AF1R1UT-
55UB
HK2EMZ01710
MB060 DOUBLE SIDE TAPE 610X3X0.86 AF1R1UT-
55UB
2EMZ01695
MB061 DOUBLE SIDE TAPE 689X3X0.86 AF1R1UT-
55UB
2EMZ01696
MB109 DIFFUSING PLATE CUSHION(T2.5) AB780UH-
65UL
HK2EMZ01205
LCD MODULE ----------
Ref.No. Description Parts No.
