Electrical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
DIGITAL MAIN CBA UNIT
IR SENSOR CBA UNIT
POWER SUPPLY CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DIGITAL MAIN CBA UNIT AF1R1MMA-001
IC3001 IC MSD95NTGW8D-3-0BJG NSAA0RMST026
IC3101 IC USB HIGH-SIDE SW AP2151WG-7/SOT25/
5PI
NSCA0TDES015
IC3102 IC EMMC NAND 64GBIT KLM8G1GETF-B041 NSCA0R0SM071
IC3202 IC RESET PST894A290UL QA2R9T0MM015
IC3601 IC DC-DC CONVERTER MP1658GTF-Z NSCA0T09M048
IC3602 IC DC-DC CONVERTER MP1658GTF-Z NSCA0T09M048
IC3603 IC DC-DC CONVERTER MP1658GTF-Z NSCA0T09M048
IC3604 IC DC-DC CONVERTER MP1657GTF-Z NSCA0T09M047
IC3605 IC DC-DC CONVERTER MP1654GTF-Z NSCA0T09M042
IC3606 IC REGULATOR BD00IC0WHFV-GTR QAADJ00RM003
IC3801 IC D-CLASS AUDIO POWER AMPLIFI
AD52060-QG28NRT
NSCA0T0E1029
IC3901 IC DC-DC CONVERTER MP2329GG-Z NSCA0T09M053
IC9001 IC SILICON TUNER SI2151-A10-GMR NSCA0T05S010
When you replace one of the below ICs on this CBA, replace with the
one that has the same part number. Do not mix ICs with different part
number.
IC3401 IC 4GB DDR3 SDRAM K4B4G1646E-BCNB NSCA0R0SM065
IC3402 IC 4GB DDR3 SDRAM K4B4G1646E-BCNB NSCA0R0SM065
or
IC3401 IC 4GB DDR3 SDRAM NT5CB256M16ER-FL NSCA0R0J2035
IC3402 IC 4GB DDR3 SDRAM NT5CB256M16ER-FL NSCA0R0J2035
or
IC3401 IC 4GB DDR3 SDRAM H5TQ4G63EFR-TEC NSCA0R0HY054
IC3402 IC 4GB DDR3 SDRAM H5TQ4G63EFR-TEC NSCA0R0HY054
Ref. No. Description Part No.
IR SENSOR CBA UNIT AF1R1MJC-001
Ref. No. Description Part No.
POWER SUPPLY CBA AF1R1MPW-001
Consists of the following
CAPACITORS
C602# CAP CERAMIC SAFETY 1000pF/250V E M RA CJMR102M42EF
C604# CAP METALLIZED FILM 0.47µF/275V_MPRC CT8N474K02T1
C605# ELECTROLYTIC CAP. 270µF/250V/M/85 CV9D271M02E7
C606 CERAMIC CAP. B K 220pF/2kV CJ9Y221KB3D1
C608 CHIP CERAMIC CAP.(1005) CH J 220pF/50V CHB1JJ3CH221
C609 CERAMIC CAP. B K 2200pF/2kV CJ9Y222KB3D1
C610 CHIP CERAMIC CAP.(1005) R1/K/0.01µF/50V CHMR103KRHB2
C611# ELECTROLYTIC CAP. 270µF/250V/M/85 CV9D271M02E7
C612 CAP CHIP 1005 K/B3/0.1µF/25V CHB1040MR004
C613# ELECTROLYTIC CAP. 270µF/250V/M/85 CV9D271M02E7
C614# CAP METALLIZED FILM 0.22µF/275V_MPRC CT8N224K02T1
C616 CAP ELE 47µF/25V/M/85 CED470KSN001
C617# CAP CERAMIC SAFETY 1000pF/250V E M RA CJMR102M42EF
C618# CAP CERAMIC SAFETY 470pF/250V B K RA CJMR471KB2EF
C619# CAP CERAMIC SAFETY 1000pF/250V E M RA CJMR102M42EF
C622 CHIP CERAMIC CAP.(1005) 2C/J/100pF/50V CHMR101JCHB2
C624# CAP CERAMIC SAFETY 470pF/250V B K RA CJMR471KB2EF
C629 CERAMIC CAP. B K 2200pF/2kV CJ9Y222KB3D1
C630 CAP METALLIZED FILM 0.1µF/275V_MPRC CT8N104K02T1
C631 CHIP CERAMIC CAP.(1005) B1/K/2200pF/50V CHMR222KBHB2
C632 CAP CHIP 1005 K/B3/0.1µF/25V CHB1040MR004
C651 CAP ELE 1000µF/25V/M/85 CED102KSN001
C652 CAP ELE 1000µF/25V/M/85 CED102KSN001
C653 CAP ELE 1000µF/16V/M/85 CEC102KSN001
C657 CAP ELE 1000µF/16V/M/85 CEC102KSN001
C658 CAP ELE 1000µF/25V/M/85 CED102KSN001
C660 CHIP CERAMIC CAP.(2012) X5R K 10µF/25V CHMR106K5EE1
C662 CAP CHIP 1005 K/B3/0.1µF/25V CHB1040MR004
C666 CHIP CERAMIC CAP.(2012) X5R K 10µF/25V CHMR106K5EE1
C667 CAP CHIP 1005 X5R/1µF/25V CHA1050SM002
C669 CHIP CERAMIC CAP.(1005) 2C/J/100pF/50V CHMR101JCHB2
C670 CHIP CERAMIC CAP.(1005) 2C/J/47pF/50V CHMR470JCHB2
C676 CHIP CERAMIC CAP.(1005) B1/K/1000pF/50V CHMR102KBHB2
C751 ELECTROLYTIC CAP. 68µF/250V M (105C) CVS6680M02ER
C752 CAP CHIP 1005 X5R/1µF/25V CHA1050SM002
C753 CHIP CERAMIC CAP.(1005) B1/K/0.022µF/16V CHMR223KBCB2
C755 CERAMIC CAP. B K 220pF/2kV CJ9Y221KB3D1
C756 CHIP CERAMIC CAP.(1005) R1/K/0.01µF/50V CHMR103KRHB2
C757 CERAMIC CAP. B K 220pF/2kV CJ9Y221KB3D1
C999 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
CONNECTORS
CN601# CONNECTOR PRINT OSU 02/R/A3963WR-
3PIN(2)
J3A302JSY001
CN651 FFC CONNECTOR 27P IMSA-9615S-27C-PP-A JC96J27ER009
CN652 CONNECTOR PRINT OSU 02 R PA-2AW J3PA02JSH004
CN1001 CONNECTOR PRINT OSU JS-1125-04(K) J3JT04CHY001
DIODES
D601# DIODE 1N5406BRV NDWZ001N5406
D602# DIODE 1N5406BRV NDWZ001N5406
D603# DIODE 1N5406BRV NDWZ001N5406
D604# DIODE 1N5406BRV NDWZ001N5406
D605# RECTIFIER DIODE 1N4005FB NDJZG1N4005F
D606 DIODE FAST RECOVERY RS1JJTD ND1Z0RS1JJTD
D607# RECTIFIER DIODE 1N4005FB NDJZG1N4005F
D608 CHIP ZENER DIODE SMFZ36V-RTK ND1ZSMFZ36RV
D609 DIODE SCHOTTKY SMD RB520SM-30 T2R QD1ZRB520SM3
D613 ZENER DIODE MM5Z5V6B ND1BMM5Z5V6B
D616 DIODE FAST RECOVERY RS1GJTD ND1Z0RS1GJTD
Ref. No. Description Part No.
